Program management and user memory
4.2 User memory and data management
SINUMERIK 802D sl pro - Milling
18 Control system overview for machine tools' sales people, 07/2008
4.2 User memory and data management
4.2.1 Buffered CNC user memory
☑ Basic configuration
SINUMERIK 802D sl pro 3 MB
Management of up to 100 part programs. For larger quantities, we recommend that part
programs be managed using the CF card.
Highlight
● Large memory space included in scope of delivery
4.2.2 Compact Flash card
☑ Basic configuration, only
CompactFlash card required
A CompactFlash card slot is located directly at the operator panel front of the
SINUMERIK 802D sl.
• Card can be inserted or removed during operation, i.e., the
machine does not have to be restarted in order for the
CompactFlash card to be recognized.
• Cover can be closed while the card is inserted in order to
protect the unit from dust.
• Load and execute part programs from the CompactFlash
card
• No loss in speed during execution of part programs from
the CompactFlash card (DNC operation)
• No special software necessary for reading/writing
CompactFlash cards via PC
Part programs on the CompactFlash card are not edited via controller, but rather via PC.
Highlight
● Efficient and reliable solution for handling a large volume of user data
