07.97 1 NC/Drive Machine Data
1 NC/Drive Machine Data
NC MD/Drive MD allocation
Meaning
MD
Softkey
0
to
999
General MDs General data
1000
to
1599
Channel-specific MDs Channel data
2000
to
3999
Axis-specific MD 1 Axial data 1
4000
to
4999
Spindle-specific MD Spindle data
5000
to
5199
General MD bits General bits
5200
to
5399
Spindle-specific MD bits Bit displays
5400
to
5599
Channel-specific MD bits 1 Channel bits 1
5600
to
5999
Axis-specific MD bits 1 Axial bits 1
6000
to
6999
Leadscrew error,
compensation bits
Compensation flags
9000
to
9299
Channel-specific MD bits 2 Channel bits 2
11000
to
17969
Axis-specific MD 2 Axial data 2
18000
to
18599
Axis-specific MD bits 2 Axial bits 2
20400
to
20449
MDs for multi-channel display Channel memory
2400*
to
3944*
MDs for parameter
set changeover, dynam. software
limit switch
Collision detection
––––––
6000*
to
62029
MDs for flexible
memory configuration
Various
axial data
1
to
18000
Simodrive drive MD
(SW 3 and higher)
––––––
4000*
to
4740*
Safety Integrated MD
(SW 5.4 and higher)
Safety functions
(see Description of Functions
Safety Integrated)
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60
1–1
SINUMERIK 840C (IA)
