01.99 1 NC/Drive Machine Data
1.2 Channel-specific values (max. 4 channels) (as from SW 4: 6 channels)
1.2 Channel-specific values (max. 4 channels)
(as from SW 4: 6 channels)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum
input value
Reference
system
Input
unit
100* Mode group 1 2
6
4)
-- --
102* Reserved
104* TO area for channel 1 4
6
4)
-- --
106* No. of enabled program 0
1)
-- --
108* Initial setting 1st G group 1 35 --
110* Initial setting 3rd G group M:17
T:18
19 -- --
112* Initial setting 6th G group 54 57 -- --
114* Initial setting 8th G group M:60
T:64
64 -- --
116* Initial setting 9th G group
0 0 -- --
118* Initial setting 12th G group M:94
T:95
97 -- --
120* Initial setting 15th G group 150 159 -- --
122* Initial setting 25th G group
3)
450 451 -- --
130* Device type for execution from
external
0 0. 5 -- --
132* Device number for execution
from external
0 0 -- --
134* Cycle number on
program start
4)
0 9 999 -- --
136* Cycle number on
program end
4)
0 9 999 -- --
140* Initial setting of
6th G group
2)
54 57 -- --
142* Initial setting of tool offset
block
2)
0 819 -- --
146* Corner deceleration speed
G620/G00
4)
0 100 000 IS 1000 units/min
148* Corner deceleration
G62 w/o G36
4)
0 100 000 IS 1000 units/min
150* Corner deceleration G62 with
G36
4)
0 100 000 IS 1000 units/min
_______
1) % +9999
L - 9999
all %, L = 0
2) SW 3 and higher
3) SW 2 and higher
4) SW 4 and higher
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60 1–9
SINUMERIK 840C (IA)
To Next Page
