Siemens SINUMERIK 840C Installation Guide

1 NC/Drive Machine Data 07.97
1.11.3 611D drive machine data FDD/MSD (as from SW 4)
1.11.3 611D drive machine data FDD/MSD (as from SW 4)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
1000 Current controller pulse rate 4 4 – 31.25 µs
1001 Speed controller pulse rate 4 16 – 31.25
µs
1002 Monitoring cycle 3 200 3 200 – 31.25 µs
1003 Configuration STS 0330 FFFF – Hex
1004 Configuration structure 0000 7FFF – Hex
1005 No. of encoder marks, motor
measuring sytem
2 048 8 192 – Incr/rev
1007 No. of encoder marks, direct
measuring sytem
0 65 535 – Incr/rev,
incr/mm
1008 Encoder phase error compens. 0.0 20.0 – Degrees
1011 Configuration, actual value
acquisition
0000 FFFF – Hex
1012 Function switch 0000 7FFF – Hex
1013 Enable star/delta changeover 0 1 – –
1014 Activate V/Hz operation
2)
0 1 -- --
1021 Multiturn resolution absolute
value encoder motor
2)
4 096 65 535 -- rev/min
1022 Meas. steps of absolute track
motor
2)
8 192 32 768 -- Incr./rev
1023 Servo loop motor absol. track
2)
0000 FFFF -- Hex
1030 Configuration actual-val. acq.,
direct meas. system
2)
0000 FFFF -- Hex
1031 Multiturn resolution absolute
value encoder, direct meas.
system
2)
4 096 4 096 -- rev/min
1032 Meas. steps of absolute track
direct meas. system
2)
8 192 32 768 -- Incr./rev
1033 Direct meas. system absolute
track
2)
0000 FFFF -- Hex
1100 Frequency pulse width
modulation
4 000/
3 200
8 000 – Hz
1101 Calculation deadtime current
closed-loop
62 124 – µs
1102 Motor code number
1)
0 65 535 – –
_______
1) SW 4 and higher
2) SW 5 and higher
1–66 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
SINUMERIK 840C (IA)
