Siemens SINUMERIK 840C Installation Guide

09.95 1 NC/Drive Machine Data
1.11.2 611D drive machine data MSD (SW 3)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
1502 Time constant speed setpoint
filter
0 500 -- ms
1600 Concealable POWER ON
611-D alarms
0000 FFFF -- HEX
1601 Concealable reset
611-D alarms
0000 FFFF -- HEX
1602 Warning threshhold motor
temperature
120 200 -- °C
1603 Timer motor temperature
alarm
240 600 -- s
1604 DC link undervoltage warning
threshold
200 600 -- V
1605 Timer speed controller at stop 200.0 10000.0 -- ms
1700 Status of binary inputs 0000 7FFF -- Hex
1701 DC link voltage 0 32 767 -- V
1702 Motor temperature 0 32 767 -- °C
1706 Speed setpoint 0.0 32 767 -- rev/min
1707 Speed actual value 0.0 32 767 -- rev/min
1708 Smoothed current actual value 0.0 32 767 -- %
1710 Significance current
representation
0.0 32 767 -- µA
1711 Significance speed
representation
0.0 32 767 -- rev/min
1720 CRC diagnosis parameter 0000 FFFF -- HEX
1797 Data version 0 32 767 -- --
1798 Firmware date 0 32 767 -- --
1799 Firmware version 0 32 767 -- --
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60 1–65
SINUMERIK 840C (IA)
