Siemens SINUMERIK 840C Installation Guide

08.96 1 NC/Drive Machine Data
1.4 Spindle-specific values (max. 6 spindles)
1.4 Spindle-specific values (max. 6 spindles)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum
input value
Reference
system
Input
unit
400* Assignment spindle 0
0
0
05 03 00 00
2)
15 02 10 15
3)
30 02 10 30
4)
ANALOG
DIGITAL
DIGITAL
--
4000
2-3
Setpoint on digital drive 0
4000
4-5
SPC/HMS setpoint output 0 12
4000
6-7
Drive/servo loop module No. 0 30
401* Drift compensation 0 +/- 500 -- VELO
2)
0.01 % of max.
motor speed
3)
402* -- -- -- --
403* Max. speed for gear stage
1
500 99999 -- rev/min
1)
404* - // - gear stage
2
1000 99999 -- rev/min
1)
405* - // - gear stage
3
4000 99999 -- rev/min
1)
406* - // - gear stage
4
4000 99999 -- rev/min
1)
407* - // - gear stage
5
4000 99999 -- rev/min
1)
408* - // - gear stage
6
4000 99999 -- rev/min
1)
409* - // - gear stage
7
4000 99999 -- rev/min
1)
410* - // - gear stage
8
4000 99999 -- rev/min
1)
411* Min. speed for gear stage
1
50 99999 -- rev/min
1)
412* - // - gear stage
2
500 99999 -- rev/min
1)
413* - // - gear stage
3
1000 99999 -- rev/min
1)
414* - // - gear stage
4
2000 99999 -- rev/min
1)
415* - // - gear stage
5
2000 99999 -- rev/min
1)
416* - // - gear stage
6
2000 99999 -- rev/min
1)
_______
1) If MD 520* bit 3 = 1, input resolution 0.1 rev/min
2) Up to SW 2
3) SW 3 and higher
4) SW 5 and higher
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60 1–13
