Siemens SINUMERIK 840C Installation Guide

1 NC/Drive Machine Data 01.99
1.3 Axis-specific values (max. 30 axes, 15 real and 15 fictitious)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum
input value
Reference
system
Input
unit
332* Tolerance band contour
monitoring
1000 99999999 MS units
336* Threshold velocity contour 5 1000000 IS 1000 units/min
344* Module value rotary axis for
leadscrew error compensation
360000 + 92160000 MS units
356* IKA warning unit
1)
±99999999 MS units
360* Mode group 1 2
6
3)
364* u: Pulses var. increment
weighting
1 16000
99999999
2)
-- --
368* v: Traversing path var.
increment weighting
2 16000
99999999
2)
MS --
372* Delay zero speed control 200 1000 ms
376* Acceleration with controlled
emergency retraction
(G425) (SW 6 and higher)
0 99 999 999 IS 10 000 units/s
2
384* Setpoint output
1)
4)
0
0
05120000
15001000
30001000
ANALOG
DIGITAL
DIGITAL
--
3840
2-3
Setpoint on digital drive
3)
0
3840
4-5
SPC/HMS setpoint output
3)
0 12
3840
6-7
Drive/servo loop
module No.
3)
0 30
388* Weighting factor for path
conversion
0 99999999 -- --
392* Time constant symmetrizing
filter
0 1000 0.1 ms
396* Absolute offset 0 99999999 MS units
_______
1) SW 3 and higher
2) SW 2 and higher
3) SW 4 and higher
4) SW 5 and higher
1–12 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
SINUMERIK 840C (IA)
