09.95 1 NC/Drive Machine Data
1.3 Axis-specific values (max. 30 axes, 15 real and 15 fictitious)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum
input value
Reference
system
Input
unit
280* Max. speed at G00 10000 99999999 IS 1000 units/min
284* Ref. point creep velocity 300 99999999 IS 1000 units/min
288* Jog velocity 2000 99999999 IS 1000 units/min
292* Jog rapid 5000 99999999 IS 1000 units/min
296* Ref. point approach velocity 10000 99999999 IS 1000 units/min
300* Incremental velocity 500 99999999 IS 1000 units/min
304* Interpolation parameter name
T:
M:
1, 2, 3
3040 = 1
3041 = 3
3042 = 0
3640 = 1
3041 = 2
3042 = 3
3
308* Cut-off frequency C encoder 200 16000 kHz
312* Feedforward factor 0 1000 0.1%
316* Reference pointer
compensation plus
0 249 -- MD offset
320* Reference pointer
compensation minus
0 249 -- MD offset
324* Distance between 2 leadscrew
error compensation values
0 32000 MS units
328* Compensation value with
leadscrew error compensation
0 100 MS units
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60 1–11
SINUMERIK 840C (IA)
