1 NC/Drive Machine Data 04.96
1.12.1 SI NC machine data
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
4116* Denominator gear unit 1
Encoder/load for safe operation
1 99999999 -- --
4120* Denominator gear unit 2
Encoder/load for safe operation
1 99999999 -- --
to
4144*
Denominator gear unit 8
Encoder/load for safe operation
1 99999999 -- --
4148* Numerator gear unit 1
Encoder/load for safe operation
1 99999999 -- --
4152* Numerator gear unit 2
Encoder/load for safe operation
1 99999999 -- --
to
4176*
Numerator gear unit 8
Encoder/load for safe operation
1 99999999 -- --
4180* Standstill tolerance for safe
operation
1000 100000 -- µ m or
0.001 degrees
4184* Limit value for safe speed 1 5000 99999999 -- 0.01 mm/min or
0.01 rev/min
4188* Limit value for safe speed 2 5000 99999999 -- 0.01 mm/min or
0.01 rev/min
4192* Limit value for safe speed 3 5000 99999999 -- 0.01 mm/min or
0.01 rev/min
4196* Limit value for safe speed 4 99999999 -- 0.01 mm/min or
0.01 rev/min
4200* Upper limit value for safe limit
position 1
100000 2147483 -- mm or degrees
4204* Upper limit value for safe limit
position 2
100000 2147483 -- mm or degrees
4208* Lower limit value for safe limit
position 1
- 100000 2147483 -- mm or degrees
4212* Lower limit value for safe limit
position 2
- 100000 2147483 -- mm or degrees
4216* Plus cam position for safe
cams 1
10 2147483 -- mm or degrees
4220* Plus cam position for safe
cams 2
10 2147483 -- mm or degrees
4224* Plus cam position for safe
cams 3
10 2147483 -- mm or degrees
4228* Plus cam position for safe
cams 4
10 2147483 -- mm or degrees
1–80 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
SINUMERIK 840C (IA)
