Siemens SINUMERIK 840D sl System Manual

Appendix A
A
A.1 Prerequisites
licenses
SINUMERIK Operate with sidescreen
Designation Article number Meaning
SINUMERIK Operate
SINUMERIK Operate /PC 6FC5800-0AP87-0YB0 License for operating SINUMERIK Operate on one PC
SINUMERIK Operate /PCU 6FC5800-0AP88-0YB0 License for operating SINUMERIK Operate on the PCU
SINUMERIK Operate /NCU 6FC5800-0AS00-0YB0 License for operating SINUMERIK Operate on the NCU
SINUMERIK Operate /universal cli‐
ent
6FC5800-0AS87-0YB0 License for operating SINUMERIK Operate on the NCU for
universal clients
SINUMERIK Operate Display Man‐
ager
6FC800-0AP81-0YB0 License for the SINUMERIK Operate Display Manager func‐
tion
SINUMERIK Operate with basic application
Designation Article number Meaning
Engineering
WinCC Advanced V15 6AV2102-0AA05-0AA5 HMI engineering software in the TIA Portal on DVD; floating
license; prerequisite for SINUMERIK INTEGRATE Create
MyHMI /WinCC V15
SINUMERIK INTEGRATE Create
MyHMI /WinCC V15
6FC5861-3YC45-0YA0 WinCC expansion for SINUMERIK 840D sl on DVD*; incl.
single license
Runtime options for a basic application running on a Simatic IPC**
SINUMERIK Operate /PCU (from
V4.8 SP2)
6FC5800-….-.YB0 SINUMERIK user interface; prerequisite for SINUMERIK
INTEGRATE Run MyHMI /WinCC
SINUMERIK INTEGRATE Run
MyHMI /WinCC V15
6FC5800-0AP61-0YB0 License for operating WinCC Runtime Advanced in SINU‐
MERIK 840D sl
Runtime options for basic application running on a 3rd party PC (no HT8, no TCU support)
SINUMERIK Operate /PC (from
V4.8 SP2)
6FC5800-….-.YB0 SINUMERIK user interface; prerequisite for SINUMERIK
INTEGRATE Run MyHMI /WinCC
SINUMERIK INTEGRATE Run
MyHMI /WinCC V15
6FC5800-0AP61-0YB0 License for operating WinCC Runtime Advanced in SINU‐
MERIK 840D sl
PC with Windows 7 Ultimate 64 bit or SIMATIC IPC with Windows Embedded Standard 7 Professional 64 bit
Note: Windows Embedded can only be used with SIMATIC IPCs that have been appropriately released.
* DVD also includes runtime software WinCC Runtime Advanced and SINUMERIK
INTEGRATE Run MyHMI /WinCC Runtime
** Use of SINUMERIK PCU Base with use of an IPC, see SIOS message
Smart machine tool operation
System Manual, 12/2017, 6FC5397-7FP40-0BA0 39

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
