2.3 ACC-AP
2.3.1 General Information
The IP-based AP door controller offers the latest technology, better cost-
effectiveness, and easy installation.
It supports:
● 2 OSDP Readers: Controller for one or 2 doors (depending on configuration)
● 4 Monitored or Unmonitored Inputs
● 2 Relay Outputs
● 4 Open-collector Outputs
● 1 general-purpose FLN bus to connect to IPM, OPM, 8IO devices and Aperio
®
AH30
● Capacity for 500,000 cards
● Maximum 5 cards per user
● Large offline event buffer with up to 200,000 events
● Anti-passback
● Linux O/S
Note: Only Input/Output devices and IAT are supported on the FLN Bus. No RIM
device support available.
The onboard Dual Reader Interface (DRIe) on the ACC-AP can be programmed to
function as any one of the door sets (Dual Reader, Two Single Readers, Dual
Reader Turnstile Contact, Single Reader Turnstile Contact) at one time.
2.3.2 Configuring the ACC-AP Controller
See section ACC-G2 USB Client Application for more details.
