2.3.3.3 OSDP Reader Turnstile, Single Door Contact Configuration
Label on AP Controller
SiPass Point Function
IN 1
Door 1 REX
IN 2
Door 1 D/C
IN 3
Door 2 REX
IN 4
In 1
RLY 1
Door 1 LK
RLY 2
Door 2 LK
OUT 1
Out 1
OUT 2
Out 2
OUT 3
Out 3
OUT 4
Out 4
READER 1
Port for connecting both OSDP Readers
READER 2
NOT USED
This configuration is not compatible with ACC-APM 12V/24V PSU Kit because IN
3 is pre-wired for power monitoring, and IN4 for cabinet tamper.
2.3.3.4 OSDP Reader Turnstile, Dual Door Contact Configuration
Label on AP Controller
SiPass Point Function
IN 1
Door 1 REX
IN 2
Door 1 D/C
IN 3
Door 2 REX
IN 4
Door 2 D/C
RLY 1
Door 1 LK
RLY 2
Door 2 LK
OUT 1
Out 1
OUT 2
Out 2
OUT 3
Out 3
OUT 4
Out 4
READER 1
Port for connecting both OSDP Readers
READER 2
NOT USED
This configuration is not compatible with ACC-APM 12V/24V PSU Kit because IN
3 is pre-wired for power monitoring, and IN4 for cabinet tamper.
