3.12.2 Connecting Aperio Hub with ACC-AP
See section Aperio Wireless Doors Extension Option [➙ 24] for details on Aperio
Wireless Hub Connection Points and ACC-AP Connection Points .
DIP Settings
DIP Switch
State
Description
1
ON
Address 0
2
OFF
Address 1
3
OFF
Address 2
4
OFF
Address 3
5
OFF
Address 4
6
OFF
Pull Down Bias – already done at ACC-AP
7
OFF
Pull Up Bias – already done at ACC-AP
8
ON
RS485 End Of Line – set the ACC-AP RS485 EOL jumper to
OFF if you intend to use a Star configuration with multiple AH30
hubs.
9
OFF
Not used
10
ON
Internal Antenna selected, set to OFF if an External Antenna is
used.
The above DIP switch settings will set the AH30 hub to
Address 1, RS485 termination enabled, Internal Antenna
If you wish to vary the above configuration, see the the Aperio Online Mechanical
Installation Manual from the AH30 Hub manufacturer (Assa Abloy) for further
details.
3.13 Help and Documentation
The hardware for Aperio Wireless Technology and Multi Function Interface (MFI) is
not supplied by Siemens. However, to help you quickly setup everything, SiPass
integrated documentation gives you the required support information sourced from
the device manufacturer. The standard SiPass firmware documentation also helps
you at places during the whole process.
While setting up the Aperio Wireless Hub and Locks and / or MFI, it is
recommended that the following documents (from SiPass integrated Software
bundle) are read in conjunction:
● SiPass integrated Controller and Device Installation Guide
● ACC-AP Technical Manual
● Multi Function Interface (MFI) Technical Manual
● SiPass integrated Configuration Client User Guide
● Aperio Wireless Lock Support Guide
Siemens does not take responsibility for the correctness of the content with
regards to the Aperio or MFI devices you may use. In case of any issues or
requirement of more information, the device manufacturer should be contacted
directly.
