2.3.3 Onboard Door (DRIe) Interfaces
NOTICE
IMPORTANT
Before connecting the Wiegand readers to the ACC AP DRIe, the End of Line
(EOL) jumper for the readers MUST BE DISABLED.
If the EOL jumpers are On (default setting), the Wiegand reader will not work.
2.3.3.1 Dual OSDP Reader Door Configuration
Label on AP Controller
SiPass Point Function
IN 1
REX
IN 2
D/C
IN 3
In 1
In case of ACC-APM 12V/24V PSU Kit, the pre-wiring is
already done for power monitoring.
IN 4
In 2
In case of ACC-APM 12V/24V PSU Kit, the pre-wiring is
already done for cabinet tamper.
RLY 1
Door 1 LK
RLY 2
Out 1
OUT 1
Door 1 AUX
OUT 2
Out 2
OUT 3
Out 3
OUT 4
Out 4
READER 1
Port for connecting both OSDP Readers
READER 2
NOT USED
2.3.3.2 2 Single OSDP Reader Doors Configuration
Label on AP Controller
SiPass Point Function
IN 1
Door 1 REX
IN 2
Door 1 D/C
IN 3
Door 2 REX
IN 4
Door 2 D/C
RLY 1
Door 1 LK
RLY 2
Door 2 LK
OUT 1
Door 1 AUX
OUT 2
Door 2 AUX
OUT 3
Out 3
OUT 4
Out 4
READER 1
Port for connecting both OSDP Readers
READER 2
NOT USED
ACC-APM can be used for this door mode if IN3 and IN4 are not used for power
monitoring and cabinet tamper.
