2
22 | 38
A6V11164550
2.3.3.5 Dual Wiegand Reader Door Configuration
Label on AP Controller
SiPass Point Function
IN 1
REX
IN 2
D/C
IN 3
In 1
In case of ACC-APM 12V/24V PSU Kit, the pre-wiring is
already done for power monitoring.
IN 4
In 2
In case of ACC-APM 12V/24V PSU Kit, the pre-wiring is
already done for cabinet tamper.
RLY 1
Door 1 LK
RLY 2
Out 1
OUT 1
Green LED for Reader 1
OUT 2
Red LED for Reader 1
OUT 3
Green LED for Reader 2
OUT 4
Red LED for Reader 2
READER 1
Pins A and B of READER 1 port are the data lines for
Wiegand Reader 1. D1 = A; D0 = B
READER 2
Pins A and B of READER 2 port are the data lines for
Wiegand Reader 2. D1 = A; D0 = B
2.3.3.6 2 Single Wiegand Reader Doors Configuration
Label on AP Controller
SiPass Point Function
IN 1
Door 1 REX
IN 2
Door 1 D/C
IN 3
Door 2 REX
IN 4
Door 2 D/C
RLY 1
Door 1 LK
RLY 2
Door 2 LK
OUT 1
Green LED for Reader 1
OUT 2
Red LED for Reader 1
OUT 3
Green LED for Reader 2
OUT 4
Red LED for Reader 2
READER 1
Pins A and B of READER 1 port are the data lines for
Wiegand Reader 1. D1 = A; D0 = B
READER 2
Pins A and B of READER 2 port are the data lines for
Wiegand Reader 2. D1 = A; D0 = B
This configuration is not compatible with ACC-APM 12V/24V PSU Kit because IN
3 is pre-wired for power monitoring, and IN4 for cabinet tamper.
