2
24 | 38
A6V11164550
2.3.4 Extension Interfaces
2.3.4.1 Extension Option
Label on AP Controller
SiPass Point Function
COMMS1
FLN 2
for MFI*, IAT and I/O devices (8IO, IPM, OPM)
*See section Multi-Function Interface (MFI) [➙ 35]
for more information.
COMMS2
Not Used
2.3.4.2 Aperio Wireless Doors Extension Option
Label on AP Controller
SiPass Point Function
COMMS1A
AH30 RS485 Data A
COMMS1B
AH30 RS485 Data B
COMMS2
Not Used
AP Vout-
AH30 GND
AP Vout+ (or READER1,2+)
AH30 PWR 8-24V
For further details, refer to the section about Aperio setup in this document.
2.3.5 Power Monitoring Limits
The AP Controller should be provided with power in the range of: 12V 24V
DC. The AP Power Supply must be protected by a fuse (2A).
An Audit Trail Message will be produced if the voltage level drops below 10.5V
or goes above 26.5V.
Absolute maximum power ratings are: 9.5V 29.5V DC.
The Reader Power Supply outputs are protected by a thermal fuse. In the
event of a short-circuit the fuse will trip. The fuse will automatically reset in
about 30 seconds if the fault has cleared.
2.3.6 Factory Reset Button
To set the IP Network Settings of the AP Controller back to its default values, hold
the Factory Reset Button down for 10 seconds during standard operation. (See
image in section Updating the AP Controller with Micro SD Card [➙ 25]).
