A.1 Ordering Information and Accessories
583
7SD5 Manual
C53000-G1176-C169-1
Mechanical Design: Housing, Number of Binary Inputs and Outputs
BI: Binary Inputs, BO: Output Relays
Pos. 9
Flush mounting housing with screwed terminals,
1
/
2
x 19”, 8 BI, 15 BO, 1 life contact A
Flush mounting housing with screwed terminals,
1
/
1
x 19”, 16 BI, 23 BO, 1 life contact C
Flush mounting housing with screwed terminals,
1
/
1
x 19”, 24 BI, 31 BO, 1 life contact D
Surface mounting housing with two-tier terminals,
1
/
2
x 19”, 8 BI, 15 BO, 1 life contact E
Surface mounting housing with two-tier terminals,
1
/
1
x 19”, 16 BI, 23 BO, 1 life contact G
Surface mounting housing with two-tier terminals,
1
/
1
x 19”, 24 BI, 31 BO, 1 life contact H
Flush mounting housing with plug-in terminals,
1
/
2
x 19”, 8 BI, 15 BO, 1 life contact J
Flush mounting housing with plug-in terminals,
1
/
1
x 19”, 16 BI, 23 BO, 1 life contact L
Flush mounting housing with plug-in terminals,
1
/
1
x 19”, 24 BI, 31 BO, 1 life contact M
Flush mounting housing with screw terminals,
1
/
1
x 19”, 16 BI, 23 BO (5 high-speed relays), 1 life contact N
Flush mounting housing with screw terminals,
1
/
1
x 19”, 24 BI, 31 BO (5 high-speed relays), 1 life contact P
Surface mounting housing with two-tier terminals,
1
/
1
x 19", 16 BI, 23 BO (5 high-speed relays), 1 life contact Q
Surface mounting housing with two-tier terminals,
1
/
1
x 19", 24 BI, 31 BO (5 high-speed relays), 1 life contact R
Flush mounting housing with plug-in terminals,
1
/
1
x 19”, 16 BI, 23 BO (5 high-speed relays), 1 life contact S
Flush mounting housing with plug-in terminals,
1
/
1
x 19”, 24 BI, 31 BO (5 high-speed relays), 1 life contact T
Region-specific Default / Language Settings and Function Versions Pos. 10
Region DE, 50 Hz, IEC, language German (language can be changed) A
Region World, 50/60 Hz, IEC/ANSI, language English (language can be changed) B
Region USA, 60/50 Hz, ANSI, language American English (language can be changed) C
Region World, 50/60 Hz, IEC/ANSI, language French (language can be changed) D
Region World, 50/60 Hz, IEC/ANSI, language Spanish (language can be changed) E
Line Differential Pro-
tection
567 89101112 13141516
With Distance Pro-
tection
7SD5 — — + L
System Interfaces (Port B) Pos. 11
No system interface 0
IEC 60870-5-103 protocol, electrical RS232 1
IEC 60870-5-103 protocol, electrical RS485 2
IEC 60870-5-103 protocol, optical 820 nm, ST connector 3
Profibus FMS Slave, electrical RS485 4
Profibus FMS Slave, optical, 820 nm, double ring, ST connector
1)
6
For more interface options see Additional Specification L 9
