A Appendix
584
7SD5 Manual
C53000-G1176-C169-1
1)
Not possible for surface mounting housing (pos. 9 = E/G/H/Q/R). For the surface mounted version, please order a device
with the appropriate electrical RS485 interface and accessories as stated in Appendix A.1.2 „External converters“.
Additional Specification
L for Further System Interfaces (Port B)
(only if Pos. 11 = 9)
Pos. 21 Pos. 22
Profibus DP Slave, electrical RS485 0 A
Profibus DP Slave, optical, 820 nm, double ring, ST connector
1)
0B
DNP 3.0, electrical RS485 0G
DNP 3.0, optical, 820 nm, double ring, ST connector
1)
0H
Line Differential Pro-
tection
5 6 7 8 9 10 11 12 13 14 15 16
With Distance Pro-
tection
7SD5 — — + M
Function Interface (Port C and D) Pos. 12
see Additional Specification M 9
Additional Specification M for DIGSI/modem interface and protection data interface 1
(device rear port C and D) (only if Pos. 12 = 9)
Pos. 23 Pos. 24
No DIGSI/modem interface (device rear) 0
Port C: DIGSI / Modem / Browser, electrical RS232 1
Port C: DIGSI / Modem / Browser, electrical RS485 2
Port C: DIGSI / Modem / Browser, optical, 820 nm, ST connector 3
Port D: optical, 820 nm, 2 ST connectors, length of optical fibre up to 1.5 km,
for direct connection or communication networks using multimode fibre
A
Port D: optical, 820 nm, 2 ST connectors, length of optical fibre up to 3.5 km,
for direct connection using multimode fibre
B
Port D: optical, 1300 nm, 2 ST connectors, length of optical fibre up to 10 km,
for direct connection using monomode fibre
C
Port D: optical, 1300 nm, 2 FC connectors, length of optical fibre up to 35 km,
for direct connection using monomode fibre
D
Port D: optical, 1300 nm, 2 LC duplex connectors, length of optical fibre up to 25 km,
for direct connection using monomode fibre
G
Port D: optical, 1300 nm, 2 LC duplex connectors, length of optical fibre up to 60 km,
for direct connection using monomode fibre
H
Port D: optical, 1550 nm, 2 LC duplex connectors, length of optical fibre up to 100 km,
for direct connection using monomode fibre
J
Line Differential Pro-
tection
5 6 7 8 9 10 11 12 13 14 15 16
With Distance Pro-
tection
7SD5 — — + N
Functions 1 and Port E: Protection Data Interface 2 Pos. 13
Three-pole tripping, without automatic reclosure, without synchronism check 0
Three-pole tripping, with automatic reclosure, without synchronism check 1
Single-/three-pole tripping, without automatic reclosure, without synchronism check 2
Single-/three-pole tripping, with automatic reclosure, without synchronism check 3
