A.1 Ordering Information and Accessories
585
7SD5 Manual
C53000-G1176-C169-1
1)
Parallel line compensation only possible if MLFB position 7 = 1 or 5
Three-pole tripping, without automatic reclosure, with synchronism check 4
Three-pole tripping, with automatic reclosure, with synchronism check 5
Single-/three-pole tripping, without automatic reclosure, with synchronism check 6
Single-/three-pole tripping, with automatic reclosure, with synchronism check 7
With protection data interface 2, see Additional Specification N 9
Functions 1 and Port E: Protection Data Interface 2 Pos. 13
Additional Specification N for functions and protection data interface 2
(Port E) (only if Pos. 13 = 9)
Pos. 25 Pos. 26
Three-pole tripping, without automatic reclosure, without synchronism check 0
Three-pole tripping, with automatic reclosure, without synchronism check 1
Single-/three-pole tripping, without automatic reclosure, without synchronism check 2
Single-/three-pole tripping, with automatic reclosure, without synchronism check 3
Three-pole tripping, without automatic reclosure, with synchronism check 4
Three-pole tripping, with automatic reclosure, with synchronism check 5
Single-/three-pole tripping, without automatic reclosure, with synchronism check 6
Single-/three-pole tripping, with automatic reclosure, with synchronism check 7
Port E: optical, 820 nm, 2 ST connectors, length of optical fibre up to 1.5 km,
for direct connection or communication networks using multimode fibre
A
Port E: optical, 820 nm, 2 ST connectors, length of optical fibre up to 3.5 km,
for direct connection using multimode fibre
B
Port E: optical, 1300 nm, 2 ST connectors, length of optical fibre up to 10 km,
for direct connection using monomode fibre
C
Port E: optical, 1300 nm, 2 FC connectors, length of optical fibre up to 35 km,
for direct connection using monomode fibre
D
Port E: optical, 1300 nm, 2 LC duplex connectors, length of optical fibre up to 25 km,
for direct connection using monomode fibre
G
Port E: optical, 1300 nm, 2 LC duplex connectors, length of optical fibre up to 60 km,
for direct connection using monomode fibre
H
Port E: optical, 1550 nm, 2 LC duplex connectors, length of optical fibre up to 100 km,
for direct connection using monomode fibre
J
Functions Pos. 14
Overcurrent Protection/
Breaker Failure Protection
Earth Fault Protection Distance Protection (pickup Z<, polygon, parallel line
compensation
1)
), power swing option with
MHO I>-, U/I/Ï• pickup
with without without without C
with without without with D
with without with without E
with with without without F
with with without with G
with with with without H
Additional Functions 1 Pos. 15
Remote Indications Transformer inside pro-
tection zone
Multi-end fault location
1)
Voltage/Frequency Protec-
tion
with without without without J
