A.1 Ordering Information and Accessories
587
7SD5 Manual
C53000-G1176-C169-1
Voltage Transform-
er Miniature Circuit
Breaker (VT mcb)
Nominal Values Order No.
Thermal 1.6 A; magnetic 6 A 3RV1611-1AG14
External
Converters
Optical interfaces for Profibus and DNP 3.0 are not possible with surface mounting
housings. Please order in this case a device with the appropriate electrical RS485 in-
terface, and the additional converters listed below
1)
.
Desired interface; order device with Additional Converter
Profibus FMS double ring; Profibus DP/FMS RS485 6GK1502-3CB01;
7XV5810-0BA00
DNP 3.0 820 nm; DNP 3.0 RS485 7XV5650-0BA00
1)
The OLM converter 6GK1502-3CB01 requires an operating voltage of 24 VDC. If the oper-
ating voltage is > 24 VDC the additional power supply 7XV5810-0BA00 is required.
Exchangeable In-
terface Modules
Name Order No.
RS232 C53207-A351-D641-1
RS485 C73207-A351-D642-1
FO 820 nm C53207-A351-D643-1
Profibus DP RS485 C53207-A351-D611-1
Profibus DP double ring C53207-A351-D613-1
Profibus FMS RS485 C53207-A351-D603-1
Profibus FMS double ring C53207-A351-D606-1
DNP 3.0 RS 485 C53207-A351-D631-3
DNP 3.0 820 nm C53207-A351-D633-3
FO5 with ST-connector; 820 nm; multimode optical fibre -
maximum length: 1.5 km
1)
C53207-A351-D651-1
FO6 with ST-connector; 820 nm; multimode optical fibre -
maximum length: 3.5 km C53207-A351-D652-1
FO7 with ST-connector; 1300 nm; monomode optical fibre
- maximum length: 10 km C53207-A351-D653-1
FO8 with ST-connector; 1300 nm; monomode optical fibre
- maximum length: 35 km C53207-A351-D654-1
FO17 with LC duplex connector; 1300 nm; monomode
optical fibre - maximum length: 24 km C53207-A351-D655-1
FO18 with LC duplex connector; 1300 nm; monomode
optical fibre - maximum length: 60 km C53207-A351-D656-1
FO19 with LC duplex connector; 1550 nm; monomode
optical fibre - maximum length: 100 km
C53207-A351-D657-1
1)
also used for connection to the optical-electrical communication converter
