Siemens siprotec 7SD5

A.3 Connection Examples
603
7SD5 Manual
C53000-G1176-C169-1
Figure A-14 Current connections to 3 current transformers with separate earth current trans-
former (summation current transformer) prefered for solidly or low-resistive
earthed systems.
