A.7 Settings
635
7SD5 Manual
C53000-G1176-C169-1
3931 PoleDiscrepancy Breaker Failure ON
OFF
OFF Pole Discrepancy supervision
3932 T-PoleDiscrep. Breaker Failure 0.00 .. 30.00 sec; ∞ 2.00 sec Trip delay with pole discrepancy
4001 FCT TripSuperv. TripCirc.Superv ON
OFF
OFF TRIP Circuit Supervision is
4002 No. of BI TripCirc.Superv 1 .. 2 2 Number of Binary Inputs per trip
circuit
4003 Alarm Delay TripCirc.Superv 1 .. 30 sec 2 sec Delay Time for alarm
4201 Ther. OVERLOAD Therm. Overload OFF
ON
Alarm Only
OFF Thermal overload protection
4202 K-FACTOR Therm. Overload 0.10 .. 4.00 1.10 K-Factor
4203 TIME CONSTANT Therm. Overload 1.0 .. 999.9 min 100.0 min Time Constant
4204 Θ ALARM Therm. Overload 50 .. 100 % 90 % Thermal Alarm Stage
4205 I ALARM Therm. Overload 1A 0.10 .. 4.00 A 1.00 A Current Overload Alarm Setpoint
5A 0.50 .. 20.00 A 5.00 A
4206 CALC. METHOD Therm. Overload Θ max
Average Θ
Θ at Imax
Θ max Method of Acquiring Tempera-
ture
4401 IP-A (A.x.x.x) Commiss. Tool 0 .. 255 141 IP-address ***.xxx.xxx.xxx(Posi-
tion 1-3)
4402 IP-B (x.B.x.x) Commiss. Tool 0 .. 255 142 IP-address xxx.***.xxx.xxx(Posi-
tion 4-6)
4403 IP-C (x.x.C.x) Commiss. Tool 0 .. 255 255 IP-address xxx.xxx.***.xxx(Posi-
tion 7-9)
4404 IP-D (x.x.x.D) Commiss. Tool 0 .. 255 150 IP-address xxx.xxx.xxx.***(Pos.
10-12)
4405 NUM LOCK Commiss. Tool YES
NO
YES Num Lock
4406 LCP/NCP Commiss. Tool NO
YES
YES Front interface supports
LCP/NCP mode
4411 IP-A (A.x.x.x) Commiss. Tool 0 .. 255 141 IP-address ***.xxx.xxx.xxx(Posi-
tion 1-3)
4412 IP-B (x.B.x.x) Commiss. Tool 0 .. 255 142 IP-address xxx.***.xxx.xxx(Posi-
tion 4-6)
4413 IP-C (x.x.C.x) Commiss. Tool 0 .. 255 255 IP-address xxx.xxx.***.xxx(Posi-
tion 7-9)
4414 IP-D (x.x.x.D) Commiss. Tool 0 .. 255 160 IP-address xxx.xxx.xxx.***(Pos.
10-12)
4415 NUM LOCK Commiss. Tool YES
NO
YES Num Lock
4416 LCP/NCP Commiss. Tool NO
YES
YES Service interface supports
LCP/NCP mode
4501 STATE PROT I 1 Prot. Interface ON
OFF
ON State of protection interface 1
4502 CONNEC. 1 OVER Prot. Interface F.optic direct
Com conv 64 kB
Com conv 128 kB
Com conv 512 kB
F.optic direct Connection 1 over
4505A PROT 1 T-DELAY Prot. Interface 0.1 .. 30.0 ms 30.0 ms Prot 1: Maximal permissible
delay time
4506A PROT 1 UNSYM. Prot. Interface 0.000 .. 3.000 ms 0.100 ms Prot 1: Diff. in send and receive
time
4509 T-DATA DISTURB Prot. Interface 0.05 .. 2.00 sec 0.10 sec Time delay for data disturbance
alarm
4510 T-DATAFAIL Prot. Interface 0.0 .. 60.0 sec 6.0 sec Time del for transmission failure
alarm
4511 PI1 SYNCMODE Prot. Interface TEL and GPS
TEL or GPS
GPS SYNC OFF
TEL and GPS PI1 Synchronizationmode
4512 Td ResetRemote Prot. Interface 0.00 .. 300.00 sec; ∞ 0.00 sec Remote signal RESET DELAY
for comm.fail
4513A PROT1 max ERROR Prot. Interface 0.5 .. 20.0 % 1.0 % Prot 1: Maximal permissible error
rate
