Page #636 background imageLoading...
Page #636 background image
A Appendix
636
7SD5 Manual
C53000-G1176-C169-1
4515A PI1 BLOCK UNSYM Prot. Interface YES
NO
YES Prot.1: Block. due to unsym.
delay time
4601 STATE PROT I 2 Prot. Interface ON
OFF
ON State of protection interface 2
4602 CONNEC. 2 OVER Prot. Interface F.optic direct
Com conv 64 kB
Com conv 128 kB
Com conv 512 kB
F.optic direct Connection 2 over
4605A PROT 2 T-DELAY Prot. Interface 0.1 .. 30.0 ms 30.0 ms Prot 2: Maximal permissible
delay time
4606A PROT 2 UNSYM. Prot. Interface 0.000 .. 3.000 ms 0.100 ms Prot 2: Diff. in send and receive
time
4611 PI2 SYNCMODE Prot. Interface TEL and GPS
TEL or GPS
GPS SYNC OFF
TEL and GPS PI2 Synchronizationmode
4613A PROT2 max ERROR Prot. Interface 0.5 .. 20.0 % 1.0 % Prot 1: Maximal permissible error
rate
4615A PI2 BLOCK UNSYM Prot. Interface YES
NO
YES Prot.2: Block. due to unsym.
delay time
4701 ID OF RELAY 1 Diff.-Topo 1 .. 65534 1 Identification number of relay 1
4702 ID OF RELAY 2 Diff.-Topo 1 .. 65534 2 Identification number of relay 2
4703 ID OF RELAY 3 Diff.-Topo 1 .. 65534 3 Identification number of relay 3
4704 ID OF RELAY 4 Diff.-Topo 1 .. 65534 4 Identification number of relay 4
4705 ID OF RELAY 5 Diff.-Topo 1 .. 65534 5 Identification number of relay 5
4706 ID OF RELAY 6 Diff.-Topo 1 .. 65534 6 Identification number of relay 6
4710 LOCAL RELAY Diff.-Topo relay 1
relay 2
relay 3
relay 4
relay 5
relay 6
relay 1 Local relay is
4801 GPS-SYNC. Prot. Interface ON
OFF
OFF GPS synchronization
4803A TD GPS FAILD Prot. Interface 0.5 .. 60.0 sec 2.1 sec Delay time for local GPS-pulse
loss
6001 S1: Line angle P.System Data 2 30 .. 89 ° 85 ° S1: Line angle
6002 S1: x' P.System Data 2 1A 0.0050 .. 9.5000 Ω/km 0.1500 Ω/km S1: feeder reactance per km: x'
5A 0.0010 .. 1.9000 Ω/km 0.0300 Ω/km
6002 S1: x' P.System Data 2 1A 0.0050 .. 15.0000 Ω/mi 0.2420 Ω/mi S1: feeder reactance per mile: x'
5A 0.0010 .. 3.0000 Ω/mi 0.0484 Ω/mi
6003 S1: c' P.System Data 2 1A 0.000 .. 100.000 µF/km 0.010 µF/km S1: feeder capacitance c' in
µF/km
5A 0.000 .. 500.000 µF/km 0.050 µF/km
6003 S1: c' P.System Data 2 1A 0.000 .. 160.000 µF/mi 0.016 µF/mi S1: feeder capacitance c' in
µF/mile
5A 0.000 .. 800.000 µF/mi 0.080 µF/mi
6004 S1: Line length P.System Data 2 0.1 .. 1000.0 km 100.0 km S1: Line length in kilometer
6004 S1: line length P.System Data 2 0.1 .. 650.0 Miles 62.1 Miles S1: Line length in kilometer
6008 S1: center ph. P.System Data 2 unknown/sym.
Phase 1
Phase 2
Phase 3
unknown/sym. S1: center phase
6009 S1: XE/XL P.System Data 2 -0.33 .. 7.00 1.00 S1: Zero seq. compensating
factor XE/XL
6010 S1: RE/RL P.System Data 2 -0.33 .. 7.00 1.00 S1: Zero seq. compensating
factor RE/RL
6011 S1: K0 P.System Data 2 0.000 .. 4.000 1.000 S1: Zero seq. compensating
factor K0
6012 S1: angle K0 P.System Data 2 -135.00 .. 135.00 ° 0.00 ° S1: Zero seq. compensating
angle of K0
6021 S2: Line angle P.System Data 2 30 .. 89 ° 85 ° S2: Line angle
6022 S2: x' P.System Data 2 1A 0.0050 .. 9.5000 Ω/km 0.1500 Ω/km S2: feeder reactance per km: x'
5A 0.0010 .. 1.9000 Ω/km 0.0300 Ω/km
6022 S2: x' P.System Data 2 1A 0.0050 .. 15.0000 Ω/mi 0.2420 Ω/mi S2: feeder reactance per mile: x'
5A 0.0010 .. 3.0000 Ω/mi 0.0484 Ω/mi
Addr. Parameter Function C Setting Options Default Setting Comments
