A.7 Settings
637
7SD5 Manual
C53000-G1176-C169-1
6023 S2: c' P.System Data 2 1A 0.000 .. 100.000 µF/km 0.010 µF/km S2: feeder capacitance c' in
µF/km
5A 0.000 .. 500.000 µF/km 0.050 µF/km
6023 S2: c' P.System Data 2 1A 0.000 .. 160.000 µF/mi 0.016 µF/mi S2: feeder capacitance c' in
µF/mile
5A 0.000 .. 800.000 µF/mi 0.080 µF/mi
6024 S2: Line length P.System Data 2 0.1 .. 1000.0 km 100.0 km S2: Line length in kilometer
6024 S2: line length P.System Data 2 0.1 .. 650.0 Miles 62.1 Miles S2: line length in miles
6028 S2: center ph. P.System Data 2 unknown/sym.
Phase 1
Phase 2
Phase 3
unknown/sym. S2: center phase
6029 S2: XE/XL P.System Data 2 -0.33 .. 7.00 1.00 S2: Zero seq. compensating
factor XE/XL
6030 S2: RE/RL P.System Data 2 -0.33 .. 7.00 1.00 S2: Zero seq. compensating
factor RE/RL
6031 S2: K0 P.System Data 2 0.000 .. 4.000 1.000 S2: Zero seq. compensating
factor K0
6032 S2: angle K0 P.System Data 2 -135.00 .. 135.00 ° 0.00 ° S2: Zero seq. compensating
angle of K0
6041 S3: Line angle P.System Data 2 30 .. 89 ° 85 ° S3: Line angle
6042 S3: x' P.System Data 2 1A 0.0050 .. 9.5000 Ω/km 0.1500 Ω/km S3: feeder reactance per km: x'
5A 0.0010 .. 1.9000 Ω/km 0.0300 Ω/km
6042 S3: x' P.System Data 2 1A 0.0050 .. 15.0000 Ω/mi 0.2420 Ω/mi S3: feeder reactance per mile: x'
5A 0.0010 .. 3.0000 Ω/mi 0.0484 Ω/mi
6043 S3: c' P.System Data 2 1A 0.000 .. 100.000 µF/km 0.010 µF/km S3: feeder capacitance c' in
µF/km
5A 0.000 .. 500.000 µF/km 0.050 µF/km
6043 S3: c' P.System Data 2 1A 0.000 .. 160.000 µF/mi 0.016 µF/mi S3: feeder capacitance c' in
µF/mile
5A 0.000 .. 800.000 µF/mi 0.080 µF/mi
6044 S3: Line length P.System Data 2 0.1 .. 1000.0 km 100.0 km S3: Line length in kilometer
6044 S3: line length P.System Data 2 0.1 .. 650.0 Miles 62.1 Miles S3: line length in miles
6048 S3: center ph. P.System Data 2 unknown/sym.
Phase 1
Phase 2
Phase 3
unknown/sym. S3: center phase
6049 S3: XE/XL P.System Data 2 -0.33 .. 7.00 1.00 S3: Zero seq. compensating
factor XE/XL
6050 S3: RE/RL P.System Data 2 -0.33 .. 7.00 1.00 S3: Zero seq. compensating
factor RE/RL
6051 S3: K0 P.System Data 2 0.000 .. 4.000 1.000 S3: Zero seq. compensating
factor K0
6052 S3: angle K0 P.System Data 2 -135.00 .. 135.00 ° 0.00 ° S3: Zero seq. compensating
angle of K0
Addr. Parameter Function C Setting Options Default Setting Comments
