1368 E/F 3I0> TRIP (EF 3I0> TRIP) Earth Fault O/C OUT * ON * LED BO 166 68 2 No
1369 E/F 3I0p TRIP (EF 3I0p TRIP) Earth Fault O/C OUT * ON * LED BO 166 69 2 No
1370 E/F Inrush picked up (EF Inrush-
PU)
Earth Fault O/C OUT * ON
OFF
*LED BO 166702No
1371 E/F Telep. Carrier SEND signal,
Phase L1 (EF Tele SEND L1)
Teleprot. E/F OUT on on * LED BO 166 71 1 No
1372 E/F Telep. Carrier SEND signal,
Phase L2 (EF Tele SEND L2)
Teleprot. E/F OUT on on * LED BO 166 72 1 No
1373 E/F Telep. Carrier SEND signal,
Phase L3 (EF Tele SEND L3)
Teleprot. E/F OUT on on * LED BO 166 73 1 No
1374 E/F Telep. Block: carrier STOP
signal L1 (EF Tele STOP L1)
Teleprot. E/F OUT * on * LED BO 166 74 2 No
1375 E/F Telep. Block: carrier STOP
signal L2 (EF Tele STOP L2)
Teleprot. E/F OUT * on * LED BO 166 75 2 No
1376 E/F Telep. Block: carrier STOP
signal L3 (EF Tele STOP L3)
Teleprot. E/F OUT * on * LED BO 166 76 2 No
1380 E/F Teleprot. ON/OFF via BI (EF
Te l eO N/o ff B I)
Teleprot. E/F IntSP ON
OFF
**LEDBO
1381 E/F Teleprotection is switched
OFF (EF Telep. OFF)
Teleprot. E/F OUT ON
OFF
* * LED BO 166 81 1 Yes
1384 E/F Telep. Carrier SEND signal
(EF Tele SEND)
Teleprot. E/F OUT on on * LED BO 166 84 2 No
1386 E/F Telep. Transient Blocking (EF
TeleTransBlk)
Teleprot. E/F OUT * ON * LED BO 166 86 2 No
1387 E/F Telep. Unblocking: FAILURE
Channel 1 (EF TeleUB Fail1)
Teleprot. E/F OUT ON
OFF
* * LED BO 166 87 1 Yes
1388 E/F Telep. Unblocking: FAILURE
Channel 2 (EF TeleUB Fail2)
Teleprot. E/F OUT ON
OFF
* * LED BO 166 88 1 Yes
1389 E/F Telep. Blocking: carrier STOP
signal (EF Tele BL STOP)
Teleprot. E/F OUT * on * LED BO 166 89 2 No
1390 E/F Tele.Blocking: Send signal
with jump (EF Tele BL Jump)
Teleprot. E/F OUT * * * LED BO 166 90 2 No
1401 >BF: Switch on breaker fail pro-
tection (>BF on)
Breaker Failure SP * * * LED BI BO
1402 >BF: Switch off breaker fail pro-
tection (>BF off)
Breaker Failure SP * * * LED BI BO
1403 >BLOCK Breaker failure
(>BLOCK BkrFail)
Breaker Failure SP ON
OFF
* * LED BI BO 166 103 1 Yes
1415 >BF: External start 3pole (>BF
Start 3pole)
Breaker Failure SP ON
OFF
**LEDBIBO
1432 >BF: External release (>BF re-
lease)
Breaker Failure SP ON
OFF
**LEDBIBO
1435 >BF: External start L1 (>BF Start
L1)
Breaker Failure SP ON
OFF
**LEDBIBO
1436 >BF: External start L2 (>BF Start
L2)
Breaker Failure SP ON
OFF
**LEDBIBO
1437 >BF: External start L3 (>BF Start
L3)
Breaker Failure SP ON
OFF
**LEDBIBO
1439 >BF: External start 3pole (w/o
current) (>BF Start w/o I)
Breaker Failure SP ON
OFF
**LEDBIBO
1440 Breaker failure prot. ON/OFF via
BI (BkrFailON/offBI)
Breaker Failure IntSP ON
OFF
**LEDBO
1451 Breaker failure is switched OFF
(BkrFail OFF)
Breaker Failure OUT ON
OFF
* * LED BO 166 151 1 Yes
1452 Breaker failure is BLOCKED
(BkrFail BLOCK)
Breaker Failure OUT ON
OFF
ON
OFF
* LED BO 166 152 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
