A.8 Information List
647
7SD5 Manual
C53000-G1176-C169-1
1325 >E/F Carrier RECEPTION,
Channel 1, Ph.L1 (>EF Rec.Ch1
L1)
Teleprot. E/F SP on
off
on * LED BI BO 166 25 1 Yes
1326 >E/F Carrier RECEPTION,
Channel 1, Ph.L2 (>EF Rec.Ch1
L2)
Teleprot. E/F SP on
off
on * LED BI BO 166 26 1 Yes
1327 >E/F Carrier RECEPTION,
Channel 1, Ph.L3 (>EF Rec.Ch1
L3)
Teleprot. E/F SP on
off
on * LED BI BO 166 27 1 Yes
1328 >E/F Unblocking: UNBLOCK
Chan. 1, Ph.L1 (>EF UB ub 1-L1)
Teleprot. E/F SP ON
OFF
ON * LED BI BO 166 28 1 Yes
1329 >E/F Unblocking: UNBLOCK
Chan. 1, Ph.L2 (>EF UB ub 1-L2)
Teleprot. E/F SP ON
OFF
ON * LED BI BO 166 29 1 Yes
1330 >E/F Unblocking: UNBLOCK
Chan. 1, Ph.L3 (>EF UB ub 1-L3)
Teleprot. E/F SP ON
OFF
ON * LED BI BO 166 30 1 Yes
1331 Earth fault protection is switched
OFF (E/F Prot. OFF)
Earth Fault O/C OUT ON
OFF
* * LED BO 166 31 1 Yes
1332 Earth fault protection is
BLOCKED (E/F BLOCK)
Earth Fault O/C OUT ON
OFF
ON
OFF
* LED BO 166 32 1 Yes
1333 Earth fault protection is ACTIVE
(E/F ACTIVE)
Earth Fault O/C OUT * * * LED BO 166 33 1 Yes
1335 Earth fault protection Trip is
blocked (EF TRIP BLOCK)
Earth Fault O/C OUT ON
OFF
ON
OFF
* LED BO
1336 E/F phase selector L1 selected
(E/F L1 selec.)
Earth Fault O/C OUT * ON
OFF
* LED BO
1337 E/F phase selector L2 selected
(E/F L2 selec.)
Earth Fault O/C OUT * ON
OFF
* LED BO
1338 E/F phase selector L3 selected
(E/F L3 selec.)
Earth Fault O/C OUT * ON
OFF
* LED BO
1345 Earth fault protection PICKED UP
(EF Pickup)
Earth Fault O/C OUT * off * LED BO 166 45 2 Yes
1354 E/F 3I0>>> PICKED UP (EF
3I0>>>Pickup)
Earth Fault O/C OUT * ON * LED BO
1355 E/F 3I0>> PICKED UP (EF 3I0>>
Pickup)
Earth Fault O/C OUT * ON * LED BO
1356 E/F 3I0> PICKED UP (EF 3I0>
Pickup)
Earth Fault O/C OUT * ON * LED BO
1357 E/F 3I0p PICKED UP (EF 3I0p
Pickup)
Earth Fault O/C OUT * ON * LED BO
1358 E/F picked up FORWARD (EF
forward)
Earth Fault O/C OUT * ON * LED BO 166 58 2 No
1359 E/F picked up REVERSE (EF re-
verse)
Earth Fault O/C OUT * ON * LED BO 166 59 2 No
1361 E/F General TRIP command (EF
Trip)
Earth Fault O/C OUT * * * LED BO 166 61 2 No
1362 Earth fault protection: Trip 1pole
L1 (E/F Trip L1)
Earth Fault O/C OUT * ON * LED BO 166 62 2 Yes
1363 Earth fault protection: Trip 1pole
L2 (E/F Trip L2)
Earth Fault O/C OUT * ON * LED BO 166 63 2 Yes
1364 Earth fault protection: Trip 1pole
L3 (E/F Trip L3)
Earth Fault O/C OUT * ON * LED BO 166 64 2 Yes
1365 Earth fault protection: Trip 3pole
(E/F Trip 3p)
Earth Fault O/C OUT * ON * LED BO 166 65 2 Yes
1366 E/F 3I0>>> TRIP (EF 3I0>>>
TRIP)
Earth Fault O/C OUT * ON * LED BO 166 66 2 No
1367 E/F 3I0>> TRIP (EF 3I0>> TRIP) Earth Fault O/C OUT * ON * LED BO 166 67 2 No
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
