7SD5 Manual
C53000-G1176-C169-1
3142 Diff: TRIP - Only L1 (Diff TRIP 1p
L1)
Diff. Prot OUT * ON
OFF
m LED BO 92 100 2 Yes
3143 Diff: TRIP - Only L2 (Diff TRIP 1p
L2)
Diff. Prot OUT * ON
OFF
m LED BO 92 101 2 Yes
3144 Diff: TRIP - Only L3 (Diff TRIP 1p
L3)
Diff. Prot OUT * ON
OFF
m LED BO 92 102 2 Yes
3145 Diff: TRIP L123 (Diff TRIP L123) Diff. Prot OUT * ON
OFF
m LED BO 92 103 2 Yes
3146 Diff: TRIP 1pole (Diff TRIP 1pole) Diff. Prot OUT * ON
OFF
*LED BO
3147 Diff: TRIP 3pole (Diff TRIP 3pole) Diff. Prot OUT * ON
OFF
*LED BO
3148 Diff: Differential protection is
blocked (Diff block)
Diff. Prot OUT ON
OFF
* * LED BO 92 104 1 Yes
3149 Diff: Diff. protection is switched off
(Diff OFF)
Diff. Prot OUT ON
OFF
* * LED BO 92 105 1 Yes
3176 Diff: Fault detection L1 (only) (Diff
Flt. 1p.L1)
Diff. Prot OUT * * * LED BO
3177 Diff: Fault detection L1E (Diff Flt.
L1E)
Diff. Prot OUT * * * LED BO
3178 Diff: Fault detection L2 (only) (Diff
Flt. 1p.L2)
Diff. Prot OUT * * * LED BO
3179 Diff: Fault detection L2E (Diff Flt.
L2E)
Diff. Prot OUT * * * LED BO
3180 Diff: Fault detection L12 (Diff Flt.
L12)
Diff. Prot OUT * * * LED BO
3181 Diff: Fault detection L12E (Diff Flt.
L12E)
Diff. Prot OUT * * * LED BO
3182 Diff: Fault detection L3 (only) (Diff
Flt. 1p.L3)
Diff. Prot OUT * * * LED BO
3183 Diff: Fault detection L3E (Diff Flt.
L3E)
Diff. Prot OUT * * * LED BO
3184 Diff: Fault detection L31 (Diff Flt.
L31)
Diff. Prot OUT * * * LED BO
3185 Diff: Fault detection L31E (Diff Flt.
L31E)
Diff. Prot OUT * * * LED BO
3186 Diff: Fault detection L23 (Diff Flt.
L23)
Diff. Prot OUT * * * LED BO
3187 Diff: Fault detection L23E (Diff Flt.
L23E)
Diff. Prot OUT * * * LED BO
3188 Diff: Fault detection L123 (Diff Flt.
L123)
Diff. Prot OUT * * * LED BO
3189 Diff: Fault detection L123E (Diff
Flt. L123E)
Diff. Prot OUT * * * LED BO
3190 Diff: Set Teststate of Diff. protec-
tion (Test Diff.)
Diff. Prot IntSP ON
OFF
**LEDFC
TN
BO 92 106 1 Yes
3191 Diff: Set Commissioning state of
Diff. (Comm. Diff)
Diff. Prot IntSP ON
OFF
**LEDFC
TN
BO 92 107 1 Yes
3192 Diff: Remote relay in Teststate
(TestDiff.remote)
Diff. Prot OUT ON
OFF
* * LED BO 92 108 1 Yes
3193 Diff: Commissioning state is
active (Comm.Diff act.)
Diff. Prot OUT ON
OFF
* * LED BO 92 109 1 Yes
3194 Diff: >Test Diff. (>Test Diff.) Diff. Prot SP ON
OFF
**LEDBIBO
3195 Diff: >Comm. Diff (>Comm. Diff) Diff. Prot SP ON
OFF
**LEDBIBO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
