A Appendix
656
7SD5 Manual
C53000-G1176-C169-1
3257 Prot.2: Delay time unsymmetry to
large (PI2 unsym.)
Prot. Interface IntSP ON
OFF
*LEDBO
3258 ProtInt1:Permissible error rate
exceeded (PI1 Error)
Prot. Interface OUT on
off
**LEDBO
3259 ProtInt2:Permissible error rate
exceeded (PI2 Error)
Prot. Interface OUT on
off
**LEDBO
3451 > Logout input signal (>Logout) Diff.-Topo SP ON
OFF
**LEDBIBO
3457 System operates in a closed
Ringtopology (Ringtopology)
Diff.-Topo OUT ON
OFF
* * LED BO 93 141 1 Yes
3458 System operates in a open
Chaintopology (Chaintopology)
Diff.-Topo OUT ON
OFF
* * LED BO 93 142 1 Yes
3464 Communication topology is com-
plete (Topol complete)
Diff.-Topo OUT ON
OFF
**LEDBO
3475 Relay 1 in Logout state
(Rel1Logout)
Diff.-Topo IntSP ON
OFF
**LEDFC
TN
BO 93 143 1 Yes
3476 Relay 2 in Logout state
(Rel2Logout)
Diff.-Topo IntSP ON
OFF
**LEDFC
TN
BO 93 144 1 Yes
3477 Relay 3 in Logout state
(Rel3Logout)
Diff.-Topo IntSP ON
OFF
**LEDFC
TN
BO 93 145 1 Yes
3478 Relay 4 in Logout state
(Rel4Logout)
Diff.-Topo IntSP ON
OFF
**LEDFC
TN
BO 93 146 1 Yes
3479 Relay 5 in Logout state
(Rel5Logout)
Diff.-Topo IntSP ON
OFF
**LEDFC
TN
BO 93 147 1 Yes
3480 Relay 6 in Logout state
(Rel6Logout)
Diff.-Topo IntSP ON
OFF
**LEDFC
TN
BO 93 148 1 Yes
3484 Local activation of Logout state
(Logout)
Diff.-Topo IntSP ON
OFF
**LEDFC
TN
BO 93 149 1 Yes
3487 Equal IDs in constellation (Equal
IDs)
Diff.-Topo OUT ON
OFF
**LEDBO
3491 Relay 1 in Login state (Rel1
Login)
Diff.-Topo OUT ON
OFF
* * LED BO 93 191 1 Yes
3492 Relay 2 in Login state (Rel2
Login)
Diff.-Topo OUT ON
OFF
* * LED BO 93 192 1 Yes
3493 Relay 3 in Login state (Rel3
Login)
Diff.-Topo OUT ON
OFF
* * LED BO 93 193 1 Yes
3494 Relay 4 in Login state (Rel4
Login)
Diff.-Topo OUT ON
OFF
* * LED BO 93 194 1 Yes
3495 Relay 5 in Login state (Rel5
Login)
Diff.-Topo OUT ON
OFF
* * LED BO 93 195 1 Yes
3496 Relay 6 in Login state (Rel6
Login)
Diff.-Topo OUT ON
OFF
* * LED BO 93 196 1 Yes
3501 I.Trip: >Intertrip L1 signal input
(>Intertrip L1)
Intertrip SP ON
OFF
**LEDBIBO
3502 I.Trip: >Intertrip L2 signal input
(>Intertrip L2)
Intertrip SP ON
OFF
**LEDBIBO
3503 I.Trip: >Intertrip L3 signal input
(>Intertrip L3)
Intertrip SP ON
OFF
**LEDBIBO
3504 I.Trip: >Intertrip 3 pole signal
input (>Intertrip 3pol)
Intertrip SP ON
OFF
**LEDBIBO
3505 I.Trip: Received at Prot.Interface
1 L1 (ITrp.rec.PI1.L1)
Intertrip OUT on
off
**LEDBO
3506 I.Trip: Received at Prot.Interface
1 L2 (ITrp.rec.PI1.L2)
Intertrip OUT on
off
**LEDBO
3507 I.Trip: Received at Prot.Interface
1 L3 (ITrp.rec.PI1.L3)
Intertrip OUT on
off
**LEDBO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
