A Appendix
670
7SD5 Manual
C53000-G1176-C169-1
10205 >BLOCK U2>(>) Overvolt. (nega-
tive seq.) (>U2>(>) BLK)
Voltage Prot. SP * * * LED BI BO
10206 >BLOCK Uph-e<(<) Undervolt
(phase-earth) (>Uph-e<(<) BLK)
Voltage Prot. SP * * * LED BI BO
10207 >BLOCK Uphph<(<) Undervolt
(phase-phase) (>Uphph<(<)
BLK)
Voltage Prot. SP * * * LED BI BO
10208 >BLOCK U1<(<) Undervolt (posi-
tive seq.) (>U1<(<) BLK)
Voltage Prot. SP * * * LED BI BO
10215 Uph-e>(>) Overvolt. is switched
OFF (Uph-e>(>) OFF)
Voltage Prot. OUT ON
OFF
**LEDBO73151Yes
10216 Uph-e>(>) Overvolt. is BLOCKED
(Uph-e>(>) BLK)
Voltage Prot. OUT ON
OFF
ON
OFF
* LED BO 73 16 1 Yes
10217 Uph-ph>(>) Overvolt. is switched
OFF (Uph-ph>(>) OFF)
Voltage Prot. OUT ON
OFF
**LEDBO73171Yes
10218 Uph-ph>(>) Overvolt. is
BLOCKED (Uph-ph>(>) BLK)
Voltage Prot. OUT ON
OFF
ON
OFF
* LED BO 73 18 1 Yes
10219 3U0>(>) Overvolt. is switched
OFF (3U0>(>) OFF)
Voltage Prot. OUT ON
OFF
**LEDBO73191Yes
10220 3U0>(>) Overvolt. is BLOCKED
(3U0>(>) BLK)
Voltage Prot. OUT ON
OFF
ON
OFF
* LED BO 73 20 1 Yes
10221 U1>(>) Overvolt. is switched OFF
(U1>(>) OFF)
Voltage Prot. OUT ON
OFF
**LEDBO73211Yes
10222 U1>(>) Overvolt. is BLOCKED
(U1>(>) BLK)
Voltage Prot. OUT ON
OFF
ON
OFF
* LED BO 73 22 1 Yes
10223 U2>(>) Overvolt. is switched OFF
(U2>(>) OFF)
Voltage Prot. OUT ON
OFF
**LEDBO73231Yes
10224 U2>(>) Overvolt. is BLOCKED
(U2>(>) BLK)
Voltage Prot. OUT ON
OFF
ON
OFF
* LED BO 73 24 1 Yes
10225 Uph-e<(<) Undervolt. is switched
OFF (Uph-e<(<) OFF)
Voltage Prot. OUT ON
OFF
**LEDBO73251Yes
10226 Uph-e<(<) Undervolt. is
BLOCKED (Uph-e<(<) BLK)
Voltage Prot. OUT ON
OFF
ON
OFF
* LED BO 73 26 1 Yes
10227 Uph-ph<(<) Undervolt. is
switched OFF (Uph-ph<(<) OFF)
Voltage Prot. OUT ON
OFF
**LEDBO73271Yes
10228 Uphph<(<) Undervolt. is
BLOCKED (Uph-ph<(<) BLK)
Voltage Prot. OUT ON
OFF
ON
OFF
* LED BO 73 28 1 Yes
10229 U1<(<) Undervolt. is switched
OFF (U1<(<) OFF)
Voltage Prot. OUT ON
OFF
**LEDBO73291Yes
10230 U1<(<) Undervolt. is BLOCKED
(U1<(<) BLK)
Voltage Prot. OUT ON
OFF
ON
OFF
* LED BO 73 30 1 Yes
10231 Over-/Under-Voltage protection is
ACTIVE (U</> ACTIVE)
Voltage Prot. OUT ON
OFF
**LEDBO73311Yes
10240 Uph-e> Pickup (Uph-e> Pickup) Voltage Prot. OUT * ON
OFF
* LED BO 73 40 2 Yes
10241 Uph-e>> Pickup (Uph-e>>
Pickup)
Voltage Prot. OUT * ON
OFF
* LED BO 73 41 2 Yes
10242 Uph-e>(>) Pickup L1 (Uph-e>(>)
PU L1)
Voltage Prot. OUT * ON
OFF
* LED BO 73 42 2 Yes
10243 Uph-e>(>) Pickup L2 (Uph-e>(>)
PU L2)
Voltage Prot. OUT * ON
OFF
* LED BO 73 43 2 Yes
10244 Uph-e>(>) Pickup L3 (Uph-e>(>)
PU L3)
Voltage Prot. OUT * ON
OFF
* LED BO 73 44 2 Yes
10245 Uph-e> TimeOut (Uph-e> Time-
Out)
Voltage Prot. OUT * * * LED BO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
