Page #671 background image
A.8 Information List
671
7SD5 Manual
C53000-G1176-C169-1
10246 Uph-e>> TimeOut (Uph-e>> Tim-
eOut)
Voltage Prot. OUT * * * LED BO
10247 Uph-e>(>) TRIP command (Uph-
e>(>) TRIP)
Voltage Prot. OUT * ON * LED BO 73 47 2 Yes
10255 Uph-ph> Pickup (Uphph> Pickup) Voltage Prot. OUT * ON
OFF
* LED BO 73 55 2 Yes
10256 Uph-ph>> Pickup (Uphph>>
Pickup)
Voltage Prot. OUT * ON
OFF
* LED BO 73 56 2 Yes
10257 Uph-ph>(>) Pickup L1-L2 (Uph-
ph>(>)PU L12)
Voltage Prot. OUT * ON
OFF
* LED BO 73 57 2 Yes
10258 Uph-ph>(>) Pickup L2-L3 (Uph-
ph>(>)PU L23)
Voltage Prot. OUT * ON
OFF
* LED BO 73 58 2 Yes
10259 Uph-ph>(>) Pickup L3-L1 (Uph-
ph>(>)PU L31)
Voltage Prot. OUT * ON
OFF
* LED BO 73 59 2 Yes
10260 Uph-ph> TimeOut (Uphph> Time-
Out)
Voltage Prot. OUT * * * LED BO
10261 Uph-ph>> TimeOut (Uphph>>
TimeOut)
Voltage Prot. OUT * * * LED BO
10262 Uph-ph>(>) TRIP command (Up-
hph>(>) TRIP)
Voltage Prot. OUT * ON * LED BO 73 62 2 Yes
10270 3U0> Pickup (3U0> Pickup) Voltage Prot. OUT * ON
OFF
* LED BO 73 70 2 Yes
10271 3U0>> Pickup (3U0>> Pickup) Voltage Prot. OUT * ON
OFF
* LED BO 73 71 2 Yes
10272 3U0> TimeOut (3U0> TimeOut) Voltage Prot. OUT * * * LED BO
10273 3U0>> TimeOut (3U0>> Time-
Out)
Voltage Prot. OUT * * * LED BO
10274 3U0>(>) TRIP command
(3U0>(>) TRIP)
Voltage Prot. OUT * ON * LED BO 73 74 2 Yes
10280 U1> Pickup (U1> Pickup) Voltage Prot. OUT * ON
OFF
* LED BO 73 80 2 Yes
10281 U1>> Pickup (U1>> Pickup) Voltage Prot. OUT * ON
OFF
* LED BO 73 81 2 Yes
10282 U1> TimeOut (U1> TimeOut) Voltage Prot. OUT * * * LED BO
10283 U1>> TimeOut (U1>> TimeOut) Voltage Prot. OUT * * * LED BO
10284 U1>(>) TRIP command (U1>(>)
TRIP)
Voltage Prot. OUT * ON * LED BO 73 84 2 Yes
10290 U2> Pickup (U2> Pickup) Voltage Prot. OUT * ON
OFF
* LED BO 73 90 2 Yes
10291 U2>> Pickup (U2>> Pickup) Voltage Prot. OUT * ON
OFF
* LED BO 73 91 2 Yes
10292 U2> TimeOut (U2> TimeOut) Voltage Prot. OUT * * * LED BO
10293 U2>> TimeOut (U2>> TimeOut) Voltage Prot. OUT * * * LED BO
10294 U2>(>) TRIP command (U2>(>)
TRIP)
Voltage Prot. OUT * ON * LED BO 73 94 2 Yes
10300 U1< Pickup (U1< Pickup) Voltage Prot. OUT * ON
OFF
* LED BO 73 100 2 Yes
10301 U1<< Pickup (U1<< Pickup) Voltage Prot. OUT * ON
OFF
* LED BO 73 101 2 Yes
10302 U1< TimeOut (U1< TimeOut) Voltage Prot. OUT * * * LED BO
10303 U1<< TimeOut (U1<< TimeOut) Voltage Prot. OUT * * * LED BO
10304 U1<(<) TRIP command (U1<(<)
TRIP)
Voltage Prot. OUT * ON * LED BO 73 104 2 Yes
10310 Uph-e< Pickup (Uph-e< Pickup) Voltage Prot. OUT * ON
OFF
* LED BO 73 110 2 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
