A Appendix
672
7SD5 Manual
C53000-G1176-C169-1
10311 Uph-e<< Pickup (Uph-e<<
Pickup)
Voltage Prot. OUT * ON
OFF
* LED BO 73 111 2 Yes
10312 Uph-e<(<) Pickup L1 (Uph-e<(<)
PU L1)
Voltage Prot. OUT * ON
OFF
*LED BO 731122Yes
10313 Uph-e<(<) Pickup L2 (Uph-e<(<)
PU L2)
Voltage Prot. OUT * ON
OFF
*LED BO 731132Yes
10314 Uph-e<(<) Pickup L3 (Uph-e<(<)
PU L3)
Voltage Prot. OUT * ON
OFF
*LED BO 731142Yes
10315 Uph-e< TimeOut (Uph-e< Time-
Out)
Voltage Prot. OUT * * * LED BO
10316 Uph-e<< TimeOut (Uph-e<< Tim-
eOut)
Voltage Prot. OUT * * * LED BO
10317 Uph-e<(<) TRIP command (Uph-
e<(<) TRIP)
Voltage Prot. OUT * ON * LED BO 73 117 2 Yes
10325 Uph-ph< Pickup (Uph-ph<
Pickup)
Voltage Prot. OUT * ON
OFF
* LED BO 73 125 2 Yes
10326 Uph-ph<< Pickup (Uph-ph<<
Pickup)
Voltage Prot. OUT * ON
OFF
* LED BO 73 126 2 Yes
10327 Uphph<(<) Pickup L1-L2 (Uph-
ph<(<)PU L12)
Voltage Prot. OUT * ON
OFF
* LED BO 73 127 2 Yes
10328 Uphph<(<) Pickup L2-L3 (Uph-
ph<(<)PU L23)
Voltage Prot. OUT * ON
OFF
* LED BO 73 128 2 Yes
10329 Uphph<(<) Pickup L3-L1 (Uph-
ph<(<)PU L31)
Voltage Prot. OUT * ON
OFF
* LED BO 73 129 2 Yes
10330 Uphph< TimeOut (Uphph< Time-
Out)
Voltage Prot. OUT * * * LED BO
10331 Uphph<< TimeOut (Uphph<<
TimeOut)
Voltage Prot. OUT * * * LED BO
10332 Uphph<(<) TRIP command (Uph-
ph<(<) TRIP)
Voltage Prot. OUT * ON * LED BO 73 132 2 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
