A Appendix
678
7SD5 Manual
C53000-G1176-C169-1
7774 Angle UL3_rem <-> UL3_loc (ΦU L3=) Measure relay1 - - - - - CFC CD DD
7781 Relay ID of 2. relay (Relay ID) Measure relay2 - - - - - CFC CD DD
7782 IL1(% of Operational nominal current)
(IL1_opN=)
Measure relay2 - - - - - CFC CD DD
7783 Angle IL1_rem <-> IL1_loc (ΦI L1=) Measure relay2 - - - - - CFC CD DD
7784 IL2(% of Operational nominal current)
(IL2_opN=)
Measure relay2 - - - - - CFC CD DD
7785 Angle IL2_rem <-> IL2_loc (ΦI L2=) Measure relay2 - - - - - CFC CD DD
7786 IL3(% of Operational nominal current)
(IL3_opN=)
Measure relay2 - - - - - CFC CD DD
7787 Angle IL3_rem <-> IL3_loc (ΦI L3=) Measure relay2 - - - - - CFC CD DD
7789 UL1(% of Operational nominal voltage)
(UL1_opN=)
Measure relay2 - - - - - CFC CD DD
7790 Angle UL1_rem <-> UL1_loc (ΦU L1=) Measure relay2 - - - - - CFC CD DD
7791 UL2(% of Operational nominal voltage)
(UL2_opN=)
Measure relay2 - - - - - CFC CD DD
7792 Angle UL2_rem <-> UL2_loc (ΦU L2=) Measure relay2 - - - - - CFC CD DD
7793 UL3(% of Operational nominal voltage)
(UL3_opN=)
Measure relay2 - - - - - CFC CD DD
7794 Angle UL3_rem <-> UL3_loc (ΦU L3=) Measure relay2 - - - - - CFC CD DD
7801 Relay ID of 3. relay (Relay ID) Measure relay3 - - - - - CFC CD DD
7802 IL1(% of Operational nominal current)
(IL1_opN=)
Measure relay3 - - - - - CFC CD DD
7803 Angle IL1_rem <-> IL1_loc (ΦI L1=) Measure relay3 - - - - - CFC CD DD
7804 IL2(% of Operational nominal current)
(IL2_opN=)
Measure relay3 - - - - - CFC CD DD
7805 Angle IL2_rem <-> IL2_loc (ΦI L2=) Measure relay3 - - - - - CFC CD DD
7806 IL3(% of Operational nominal current)
(IL3_opN=)
Measure relay3 - - - - - CFC CD DD
7807 Angle IL3_rem <-> IL3_loc (ΦI L3=) Measure relay3 - - - - - CFC CD DD
7809 UL1(% of Operational nominal voltage)
(UL1_opN=)
Measure relay3 - - - - - CFC CD DD
7810 Angle UL1_rem <-> UL1_loc (ΦU L1=) Measure relay3 - - - - - CFC CD DD
7811 UL2(% of Operational nominal voltage)
(UL2_opN=)
Measure relay3 - - - - - CFC CD DD
7812 Angle UL2_rem <-> UL2_loc (ΦU L2=) Measure relay3 - - - - - CFC CD DD
7813 UL3(% of Operational nominal voltage)
(UL3_opN=)
Measure relay3 - - - - - CFC CD DD
7814 Angle UL3_rem <-> UL3_loc (ΦU L3=) Measure relay3 - - - - - CFC CD DD
7821 Relay ID of 4. relay (Relay ID) Measure relay4 - - - - - CFC CD DD
7822 IL1(% of Operational nominal current)
(IL1_opN=)
Measure relay4 - - - - - CFC CD DD
7823 Angle IL1_rem <-> IL1_loc (ΦI L1=) Measure relay4 - - - - - CFC CD DD
7824 IL2(% of Operational nominal current)
(IL2_opN=)
Measure relay4 - - - - - CFC CD DD
7825 Angle IL2_rem <-> IL2_loc (ΦI L2=) Measure relay4 - - - - - CFC CD DD
7826 IL3(% of Operational nominal current)
(IL3_opN=)
Measure relay4 - - - - - CFC CD DD
7827 Angle IL3_rem <-> IL3_loc (ΦI L3=) Measure relay4 - - - - - CFC CD DD
7829 UL1(% of Operational nominal voltage)
(UL1_opN=)
Measure relay4 - - - - - CFC CD DD
7830 Angle UL1_rem <-> UL1_loc (ΦU L1=) Measure relay4 - - - - - CFC CD DD
7831 UL2(% of Operational nominal voltage)
(UL2_opN=)
Measure relay4 - - - - - CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
