Siemens siprotec 7SD5 User Manual

A.10 Measured Values
679
7SD5 Manual
C53000-G1176-C169-1
7832 Angle UL2_rem <-> UL2_loc (ΦU L2=) Measure relay4 - - - - - CFC CD DD
7833 UL3(% of Operational nominal voltage)
(UL3_opN=)
Measure relay4 - - - - - CFC CD DD
7834 Angle UL3_rem <-> UL3_loc (ΦU L3=) Measure relay4 - - - - - CFC CD DD
7841 Relay ID of 5. relay (Relay ID) Measure relay5 - - - - - CFC CD DD
7842 IL1(% of Operational nominal current)
(IL1_opN=)
Measure relay5 - - - - - CFC CD DD
7843 Angle IL1_rem <-> IL1_loc (ΦI L1=) Measure relay5 - - - - - CFC CD DD
7844 IL2(% of Operational nominal current)
(IL2_opN=)
Measure relay5 - - - - - CFC CD DD
7845 Angle IL2_rem <-> IL2_loc (ΦI L2=) Measure relay5 - - - - - CFC CD DD
7846 IL3(% of Operational nominal current)
(IL3_opN=)
Measure relay5 - - - - - CFC CD DD
7847 Angle IL3_rem <-> IL3_loc (ΦI L3=) Measure relay5 - - - - - CFC CD DD
7849 UL1(% of Operational nominal voltage)
(UL1_opN=)
Measure relay5 - - - - - CFC CD DD
7850 Angle UL1_rem <-> UL1_loc (ΦU L1=) Measure relay5 - - - - - CFC CD DD
7851 UL2(% of Operational nominal voltage)
(UL2_opN=)
Measure relay5 - - - - - CFC CD DD
7852 Angle UL2_rem <-> UL2_loc (ΦU L2=) Measure relay5 - - - - - CFC CD DD
7853 UL3(% of Operational nominal voltage)
(UL3_opN=)
Measure relay5 - - - - - CFC CD DD
7854 Angle UL3_rem <-> UL3_loc (ΦU L3=) Measure relay5 - - - - - CFC CD DD
7861 Relay ID of 6. relay (Relay ID) Measure relay6 - - - - - CFC CD DD
7862 IL1(% of Operational nominal current)
(IL1_opN=)
Measure relay6 - - - - - CFC CD DD
7863 Angle IL1_rem <-> IL1_loc (ΦI L1=) Measure relay6 - - - - - CFC CD DD
7864 IL2(% of Operational nominal current)
(IL2_opN=)
Measure relay6 - - - - - CFC CD DD
7865 Angle IL2_rem <-> IL2_loc (ΦI L2=) Measure relay6 - - - - - CFC CD DD
7866 IL3(% of Operational nominal current)
(IL3_opN=)
Measure relay6 - - - - - CFC CD DD
7867 Angle IL3_rem <-> IL3_loc (ΦI L3=) Measure relay6 - - - - - CFC CD DD
7869 UL1(% of Operational nominal voltage)
(UL1_opN=)
Measure relay6 - - - - - CFC CD DD
7870 Angle UL1_rem <-> UL1_loc (ΦU L1=) Measure relay6 - - - - - CFC CD DD
7871 UL2(% of Operational nominal voltage)
(UL2_opN=)
Measure relay6 - - - - - CFC CD DD
7872 Angle UL2_rem <-> UL2_loc (ΦU L2=) Measure relay6 - - - - - CFC CD DD
7873 UL3(% of Operational nominal voltage)
(UL3_opN=)
Measure relay6 - - - - - CFC CD DD
7874 Angle UL3_rem <-> UL3_loc (ΦU L3=) Measure relay6 - - - - - CFC CD DD
7875 Prot.Interface 1:Transmission delay rec. (PI1
TD R)
Statistics 134 121 No 9 1 CFC CD DD
7876 Prot.Interface 1:Transmission delay send
(PI1 TD S)
Statistics 134 121 No 9 2 CFC CD DD
7877 Prot.Interface 2:Transmission delay rec. (PI2
TD R)
Statistics 134 121 No 9 4 CFC CD DD
7878 Prot.Interface 2:Transmission delay send
(PI2 TD S)
Statistics 134 121 No 9 5 CFC CD DD
7880 Measured value charging current L1 (Ic L1 =) IDiff/IRest - - - - - CFC CD DD
7881 Measured value charging current L2 (Ic L2 =) IDiff/IRest - - - - - CFC CD DD
7882 Measured value charging current L3 (Ic L3 =) IDiff/IRest - - - - - CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
