2.32 RTD-Box
199
7UM61 Manual
C53000-G1176-C127-3
2.32.4 Information List
9121A RTD12 TYPE Not connected
Pt 100 Ω
Ni 120 Ω
Ni 100 Ω
Not connected RTD12: Type
9122A RTD12 LOCATION Oil
Ambient
Winding
Bearing
Other
Other RTD12: Location
9123 RTD12 STAGE 1 -50 .. 250 °C; ∞ 100 °C RTD12: Temperature Stage 1
Pickup
9124 RTD12 STAGE 1 -58 .. 482 °F; ∞ 212 °F RTD12: Temperature Stage 1
Pickup
9125 RTD12 STAGE 2 -50 .. 250 °C; ∞ 120 °C RTD12: Temperature Stage 2
Pickup
9126 RTD12 STAGE 2 -58 .. 482 °F; ∞ 248 °F RTD12: Temperature Stage 2
Pickup
No. Information Type of In-
formation
Comments
14101 Fail: RTD AM Fail: RTD (broken wire/shorted)
14111 Fail: RTD 1 AM Fail: RTD 1 (broken wire/shorted)
14112 RTD 1 St.1 p.up AM RTD 1 Temperature stage 1 picked up
14113 RTD 1 St.2 p.up AM RTD 1 Temperature stage 2 picked up
14121 Fail: RTD 2 AM Fail: RTD 2 (broken wire/shorted)
14122 RTD 2 St.1 p.up AM RTD 2 Temperature stage 1 picked up
14123 RTD 2 St.2 p.up AM RTD 2 Temperature stage 2 picked up
14131 Fail: RTD 3 AM Fail: RTD 3 (broken wire/shorted)
14132 RTD 3 St.1 p.up AM RTD 3 Temperature stage 1 picked up
14133 RTD 3 St.2 p.up AM RTD 3 Temperature stage 2 picked up
14141 Fail: RTD 4 AM Fail: RTD 4 (broken wire/shorted)
14142 RTD 4 St.1 p.up AM RTD 4 Temperature stage 1 picked up
14143 RTD 4 St.2 p.up AM RTD 4 Temperature stage 2 picked up
14151 Fail: RTD 5 AM Fail: RTD 5 (broken wire/shorted)
14152 RTD 5 St.1 p.up AM RTD 5 Temperature stage 1 picked up
14153 RTD 5 St.2 p.up AM RTD 5 Temperature stage 2 picked up
14161 Fail: RTD 6 AM Fail: RTD 6 (broken wire/shorted)
14162 RTD 6 St.1 p.up AM RTD 6 Temperature stage 1 picked up
14163 RTD 6 St.2 p.up AM RTD 6 Temperature stage 2 picked up
14171 Fail: RTD 7 AM Fail: RTD 7 (broken wire/shorted)
14172 RTD 7 St.1 p.up AM RTD 7 Temperature stage 1 picked up
14173 RTD 7 St.2 p.up AM RTD 7 Temperature stage 2 picked up
14181 Fail: RTD 8 AM Fail: RTD 8 (broken wire/shorted)
14182 RTD 8 St.1 p.up AM RTD 8 Temperature stage 1 picked up
Addr. Parameter Setting Options Default Setting Comments
