2.13 Forward Active Power Supervision (ANSI 32F)
91
7UM61 Manual
C53000-G1176-C127-3
2.13.3 Settings
Addresses which have an appended "A" can only be changed with DIGSI, under Ad-
ditional Settings.
2.13.4 Information List
Addr. Parameter Setting Options Default Setting Comments
3201 FORWARD POWER OFF
ON
Block relay
OFF Forward Power Supervision
3202 Pf< 0.5 .. 120.0 % 9.7 % P-forw.< Supervision Pickup
3203 T-Pf< 0.00 .. 60.00 sec; ∞ 10.00 sec T-P-forw.< Time Delay
3204 Pf> 1.0 .. 120.0 % 96.6 % P-forw.> Supervision Pickup
3205 T-Pf> 0.00 .. 60.00 sec; ∞ 10.00 sec T-P-forw.> Time Delay
3206A MEAS. METHOD accurate
fast
accurate Method of Operation
No. Information Type of In-
formation
Comments
5113 >Pf BLOCK EM >BLOCK forward power supervision
5116 >Pf< BLOCK EM >BLOCK forw. power superv. Pf< stage
5117 >Pf> BLOCK EM >BLOCK forw. power superv. Pf> stage
5121 Pf OFF AM Forward power supervis. is switched OFF
5122 Pf BLOCKED AM Forward power supervision is BLOCKED
5123 Pf ACTIVE AM Forward power supervision is ACTIVE
5126 Pf< picked up AM Forward power: Pf< stage picked up
5127 Pf> picked up AM Forward power: Pf> stage picked up
5128 Pf< TRIP AM Forward power: Pf< stage TRIP
5129 Pf> TRIP AM Forward power: Pf> stage TRIP
