Siemens Siprotec 7UM612 - Panel Flush and Cubicle Mounting - 7 UM612

4 Technical Data
346
7UM61 Manual
C53000-G1176-C127-3
4.26.2 Panel Flush and Cubicle Mounting – 7UM612
Figure 4-8 Dimensions of a 7UM612 for panel flush mounting or cubicle installation (housing size 1/2)
