A Appendix
584
7UT613/63x Manual
C53000-G1176-C160-2
023.2404 >BLOCK Phase time overcurrent
(>BLK Phase O/C)
Phase O/C SP * * * LED BI BO
023.2411 Time Overcurrent Phase is OFF
(O/C Phase OFF)
Phase O/C OUT ON
OFF
**LEDBO60211Yes
023.2412 Time Overcurrent Phase is
BLOCKED (O/C Phase BLK)
Phase O/C OUT ON
OFF
ON
OFF
* LED BO 60 22 1 Yes
023.2413 Time Overcurrent Phase is
ACTIVE (O/C Phase ACT)
Phase O/C OUT ON
OFF
**LEDBO60231Yes
023.2422 Time Overcurrent Phase L1
picked up (O/C Ph L1 PU)
Phase O/C OUT * ON
OFF
m LED BO 60 112 2 Yes
023.2423 Time Overcurrent Phase L2
picked up (O/C Ph L2 PU)
Phase O/C OUT * ON
OFF
m LED BO 60 113 2 Yes
023.2424 Time Overcurrent Phase L3
picked up (O/C Ph L3 PU)
Phase O/C OUT * ON
OFF
m LED BO 60 114 2 Yes
023.2491 O/C Phase: Not available for this
object (O/C Ph. Not av.)
Phase O/C OUT ON * * LED BO
023.2501 >BLOCK time overcurrent Phase
InRush (>BLK Ph.O/C Inr)
Phase O/C SP ON
OFF
ON
OFF
* LED BI BO 60 98 1 Yes
023.2502 >BLOCK I>> (>BLOCK I>>) Phase O/C SP * * * LED BI BO 60 1 1 Yes
023.2503 >BLOCK I> (>BLOCK I>) Phase O/C SP * * * LED BI BO 60 2 1 Yes
023.2504 >BLOCK Ip (>BLOCK Ip) Phase O/C SP * * * LED BI BO 60 3 1 Yes
023.2514 I>> BLOCKED (I>> BLOCKED) Phase O/C OUT ON
OFF
ON
OFF
* LED BO 60 106 1 Yes
023.2515 I> BLOCKED (I> BLOCKED) Phase O/C OUT ON
OFF
ON
OFF
* LED BO 60 105 1 Yes
023.2516 Ip BLOCKED (Ip BLOCKED) Phase O/C OUT ON
OFF
ON
OFF
* LED BO 60 109 1 Yes
023.2521 I>> picked up (I>> picked up) Phase O/C OUT * ON
OFF
* LED BO 60 75 2 Yes
023.2522 I> picked up (I> picked up) Phase O/C OUT * ON
OFF
* LED BO 60 76 2 Yes
023.2523 Ip picked up (Ip picked up) Phase O/C OUT * ON
OFF
* LED BO 60 77 2 Yes
023.2524 I> InRush picked up (I> InRush
PU)
Phase O/C OUT * ON
OFF
* LED BO 60 80 2 Yes
023.2525 Ip InRush picked up (Ip InRush
PU)
Phase O/C OUT * ON
OFF
* LED BO 60 82 2 Yes
023.2526 Phase L1 InRush picked up (L1
InRush PU)
Phase O/C OUT * ON
OFF
* LED BO 60 89 2 Yes
023.2527 Phase L2 InRush picked up (L2
InRush PU)
Phase O/C OUT * ON
OFF
* LED BO 60 90 2 Yes
023.2528 Phase L3 InRush picked up (L3
InRush PU)
Phase O/C OUT * ON
OFF
* LED BO 60 91 2 Yes
023.2531 Phase L1 InRush detected (L1
InRush det.)
Phase O/C OUT * ON
OFF
* LED BO
023.2532 Phase L2 InRush detected (L2
InRush det.)
Phase O/C OUT * ON
OFF
* LED BO
023.2533 Phase L3 InRush detected (L3
InRush det.)
Phase O/C OUT * ON
OFF
* LED BO
023.2534 Cross blk: PhX blocked PhY
(INRUSH X-BLK)
Phase O/C OUT * ON
OFF
* LED BO
023.2541 I>> Time Out (I>> Time Out) Phase O/C OUT * * * LED BO 60 49 2 Yes
023.2542 I> Time Out (I> Time Out) Phase O/C OUT * * * LED BO 60 53 2 Yes
023.2543 Ip Time Out (Ip Time Out) Phase O/C OUT * * * LED BO 60 57 2 Yes
023.2551 I>> TRIP (I>> TRIP) Phase O/C OUT * ON * LED BO 60 70 2 Yes
No. Description Function
Type of Information
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
