A.9 Information List
585
7UT613/63x Manual
C53000-G1176-C160-2
023.2552 I> TRIP (I> TRIP) Phase O/C OUT * ON * LED BO 60 71 2 Yes
023.2553 Ip TRIP (Ip TRIP) Phase O/C OUT * ON * LED BO 60 58 2 Yes
024.2404 >BLOCK Earth time overcurrent
(>BLK Earth O/C)
Earth O/C SP * * * LED BI BO
024.2411 Time Overcurrent Earth is OFF
(O/C Earth OFF)
Earth O/C OUT ON
OFF
**LEDBO60261Yes
024.2412 Time Overcurrent Earth is
BLOCKED (O/C Earth BLK)
Earth O/C OUT ON
OFF
ON
OFF
* LED BO 60 27 1 Yes
024.2413 Time Overcurrent Earth is
ACTIVE (O/C Earth ACT)
Earth O/C OUT ON
OFF
**LEDBO60281Yes
024.2425 Time Overcurrent Earth picked up
(O/C Earth PU)
Earth O/C OUT * ON
OFF
m LED BO 60 67 2 Yes
024.2492 O/C Earth err.: No auxiliary CT
assigned (O/C Earth ErrCT)
Earth O/C OUT ON * * LED BO
024.2501 >BLOCK time overcurrent Earth
InRush (>BLK E O/C Inr)
Earth O/C SP ON
OFF
ON
OFF
* LED BI BO 60 100 1 Yes
024.2502 >BLOCK IE>> (>BLOCK IE>>) Earth O/C SP * * * LED BI BO 60 4 1 Yes
024.2503 >BLOCK IE> (>BLOCK IE>) Earth O/C SP * * * LED BI BO 60 5 1 Yes
024.2504 >BLOCK IEp (>BLOCK IEp) Earth O/C SP * * * LED BI BO 60 6 1 Yes
024.2514 IE>> BLOCKED (IE>>
BLOCKED)
Earth O/C OUT ON
OFF
ON
OFF
* LED BO 60 108 1 Yes
024.2515 IE> BLOCKED (IE> BLOCKED) Earth O/C OUT ON
OFF
ON
OFF
* LED BO 60 107 1 Yes
024.2516 IEp BLOCKED (IEp BLOCKED) Earth O/C OUT ON
OFF
ON
OFF
* LED BO 60 110 1 Yes
024.2521 IE>> picked up (IE>> picked up) Earth O/C OUT * ON
OFF
* LED BO 60 59 2 Yes
024.2522 IE> picked up (IE> picked up) Earth O/C OUT * ON
OFF
* LED BO 60 62 2 Yes
024.2523 IEp picked up (IEp picked up) Earth O/C OUT * ON
OFF
* LED BO 60 64 2 Yes
024.2524 IE> InRush picked up (IE>
InRush PU)
Earth O/C OUT * ON
OFF
* LED BO 60 81 2 Yes
024.2525 IEp InRush picked up (IEp
InRush PU)
Earth O/C OUT * ON
OFF
* LED BO 60 83 2 Yes
024.2529 Earth InRush picked up (Earth
InRush PU)
Earth O/C OUT * ON
OFF
* LED BO 60 88 2 Yes
024.2541 IE>> Time Out (IE>> Time Out) Earth O/C OUT * * * LED BO 60 60 2 Yes
024.2542 IE> Time Out (IE> Time Out) Earth O/C OUT * * * LED BO 60 63 2 Yes
024.2543 IEp Time Out (IEp TimeOut) Earth O/C OUT * * * LED BO 60 65 2 Yes
024.2551 IE>> TRIP (IE>> TRIP) Earth O/C OUT * ON * LED BO 60 61 2 Yes
024.2552 IE> TRIP (IE> TRIP) Earth O/C OUT * ON * LED BO 60 72 2 Yes
024.2553 IEp TRIP (IEp TRIP) Earth O/C OUT * ON * LED BO 60 66 2 Yes
025.2413 Dynamic settings O/C Phase are
ACTIVE (I Dyn.set. ACT)
ColdLoadPickup OUT ON
OFF
ON
OFF
* LED BO 60 248 1 Yes
026.2413 Dynamic settings O/C Earth are
ACTIVE (IE Dyn.set. ACT)
ColdLoadPickup OUT ON
OFF
ON
OFF
* LED BO 60 250 1 Yes
033.2404 >BLOCK undervoltage protection
(>BLOCK U/V)
Undervoltage SP * * * LED BI BO
033.2411 Undervoltage protection is
switched OFF (Undervolt. OFF)
Undervoltage OUT ON
OFF
**LEDBO74301Yes
033.2412 Undervoltage protection is
BLOCKED (Undervolt. BLK)
Undervoltage OUT ON
OFF
ON
OFF
* LED BO 74 31 1 Yes
No. Description Function
Type of Information
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
