Appendix
A.1 Ordering Information and Accessories
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
643
Mechanical Design: Housing, Number of Binary Inputs and Outputs
BI: Binary Inputs, BO: Output Relays
Pos. 9
Flush mounting housing with screwed terminals,
1
/
2
x 19”, 8 BI, 15 BO, 1 life contact A
Flush mounting housing with screwed terminals,
1
/
1
x 19”, 16 BI, 23 BO, 1 life contact C
Flush mounting housing with screwed terminals,
1
/
1
x 19”, 24 BI, 31 BO, 1 life contact D
Surface mounting housing with two-tier terminals,
1
/
2
x 19”, 8 BI, 15 BO, 1 life contact E
Surface mounting housing with two-tier terminals,
1
/
1
x 19”, 16 BI, 23 BO, 1 life contact G
Surface mounting housing with two-tier terminals,
1
/
1
x 19”, 24 BI, 31 BO, 1 life contact H
Flush mounting housing with plug-in terminals,
1
/
2
x 19”, 8 BI, 15 BO, 1 life contact J
Flush mounting housing with plug-in terminals,
1
/
1
x 19”, 16 BI, 23 BO, 1 life contact L
Flush mounting housing with plug-in terminals,
1
/
1
x 19”, 24 BI, 31 BO, 1 life contact M
Flush mounting housing with screwed terminals,
1
/
1
x 19”, 16 BI, 23 BO, 1 life contact
With 5 „high speed relays“, trip command accelerated by 5 ms
N
Flush mounting housing with screwed terminals,
1
/
1
x 19”, 24 BI, 31 BO, 1 life contact
With 5 „high speed relays“, trip command accelerated by 5 ms
P
Surface mounting housing with two-tier terminals,
1
/
1
x 19”, 16 BI, 23 BO, 1 life contact
With 5 „high speed relays“, trip command accelerated by 5 ms
Q
Surface mounting housing with two-tier terminals,
1
/
1
x 19”, 24 BI, 31 BO, 1 life contact
With 5 „high speed relays“, trip command accelerated by 5 ms
R
Flush mounting housing with plug-in terminals,
1
/
1
x 19”, 16 BI, 23 BO, 1 life contact
With 5 „high speed relays“, trip command accelerated by 5 ms
S
Flush mounting housing with plug-in terminals,
1
/
1
x 19”, 24 BI, 31 BO, 1 life contact
With 5 „high speed relays“, trip command accelerated by 5 ms
T
Flush mounting housing with screwed terminals,
1
/
1
x 19”, 24 BI, 31 BO, 1 life contact
With 10 „high speed relays“, trip command accelerated by 5 ms
W
Region-specific Default / Language Settings and Function Versions Pos. 10
Region DE, 50 Hz, IEC, language German (language can be changed) A
Region: World, 50 Hz/60 Hz, IEC/ANSI, language: English (language can be changed) B
Region: USA, 60 Hz/50 Hz, ANSI, language: American English (language can be changed) C
Region: World, 50 Hz/60 Hz, IEC/ANSI, language: French (language can be changed) D
Region: World, 50 Hz/60 Hz, IEC/ANSI, language: Spanish (language can be changed) E
