Appendix
A.1 Ordering Information and Accessories
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
644
1)
Not possible for surface mounting housing (MLFB position 9 = E/G/H/Q/R). For the surface mounting version, please
order a device with the appropriate electrical RS485 interface and accessories as stated in Appendix A.1.2 „External
converters“.
2)
Not possible for surface mounting housing (MLFB position 9 = E/G/H/Q/R). Please order the device with electrical inter-
face and use a separate fibre-optic switch.
Line Differential
Protection
5 6 7 8 9 10 11 12 13 14 15 16
With Distance
Protection
7SD5 — — + L
System Interfaces (Port B) Pos. 11
No system interface 0
IEC 60870-5-103 protocol, electrical RS232 1
IEC 60870-5-103 protocol, electrical RS485 2
IEC 60870-5-103 protocol, optical 820 nm, ST connector 3
Profibus FMS Slave, electrical RS485 4
Profibus FMS Slave, optical, 820 nm, double ring, ST connector
1)
6
For more interface options see Additional Specification L 9
Additional Specification L for Further System Interfaces (Port B)
(only if Pos. 11 = 9)
Pos. 21 Pos. 22
Profibus DP Slave, electrical RS485 0 A
Profibus DP Slave, optical, 820 nm, double ring, ST connector
1)
0B
DNP 3.0, electrical RS485 0G
DNP 3.0, optical, 820 nm, double ring, ST connector
1)
0H
IEC 61850, 100 MBit Ethernet, double electrical, RJ45 connector 0 R
IEC 61850, 100 MBit Ethernet, optical, double, Duplex LC connector
2)
0S
