Appendix
A.1 Ordering Information and Accessories
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
645
1)
for surface-mounting housing, delivery with external repeater
2)
This interface is not available in the surface-mounting housing (MLFB position 9 = E/G/H/Q/R).
Line Differential
Protection
5 6 7 8 9 101112 13141516
With Distance
Protection
7SD5 — — + M
Function Interface (Port C and D) Pos. 12
see Additional Specification M 9
Additional Specification M for DIGSI/modem interface and protection data interface 1
(device rear port C and D) (only if Pos. 12 = 9)
Pos. 23 Pos. 24
No DIGSI/modem interface (device rear) 0
Port C: DIGSI / Modem / Browser, electrical RS232 1
Port C: DIGSI / Modem / Browser, electrical RS485 2
Port C: DIGSI / Modem / Browser, optical, 820 nm, ST connector 3
Port D: FO5 optical, 820 nm, 2 ST connectors, length of optical fibre up to 1.5 km,
for FO direct connection or communication networks using multimode fibre
A
Port D: FO6 optical, 820 nm, 2 ST connectors, length of optical fibre up to 3.5 km,
for FO direct connection using multimode fibre
B
Port D: FO17 optical, 1300 nm, LC duplex connector, length of optical fibre up to 24 km,
for FO direct connection using multimode fibre
1)
G
Port D: FO18 optical, 1300 nm, LC duplex connector, length of optical fibre up to 60 km,
for FO direct connection using multimode fibre
1)
H
Port D: FO19 optical, 1550 nm, LC duplex connector, length of optical fibre up to 100 km,
for FO direct connection using multimode fibre
1)
J
Port D: FO30 optical, 820 nm, 2 ST connectors, length of optical fibre up to 1.5 km,
for FO direct connection or communication networks with IEEE C37.94 interface using multimode
fibre
2)
S
