Appendix
A.1 Ordering Information and Accessories
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
646
1)
for surface-mounting housing, delivery with external repeater
2)
This interface is not available in the surface-mounting housing (MLFB position 9 = E/G/H/Q/R).
Line Differential
Protection
5 6 7 8 9 10 11 12 13 14 15 16
With Distance
Protection
7SD5 — — + N
Functions 1 and Port E: Protection Data Interface 2 Pos. 13
Three-pole tripping, without automatic reclosure, without synchronism check 0
Three-pole tripping, with automatic reclosure, without synchronism check 1
Single-/three-pole tripping, without automatic reclosure, without synchronism check 2
Single-/three-pole tripping, with automatic reclosure, without synchronism check 3
Three-pole tripping, without automatic reclosure, with synchronism check 4
Three-pole tripping, with automatic reclosure, with synchronism check 5
Single-/three-pole tripping, without automatic reclosure, with synchronism check 6
Single-/three-pole tripping, with automatic reclosure, with synchronism check 7
With protection data interface 2, see Additional Specification N 9
Additional Specification
N for functions and protection data interface 2
(Port E) (only if Pos. 13 = 9)
Pos. 25 Pos. 26
Three-pole tripping, without automatic reclosure, without synchronism check 0
Three-pole tripping, with automatic reclosure, without synchronism check 1
Single-/three-pole tripping, without automatic reclosure, without synchronism check 2
Single-/three-pole tripping, with automatic reclosure, without synchronism check 3
Three-pole tripping, without automatic reclosure, with synchronism check 4
Three-pole tripping, with automatic reclosure, with synchronism check 5
Single-/three-pole tripping, without automatic reclosure, with synchronism check 6
Single-/three-pole tripping, with automatic reclosure, with synchronism check 7
1-/3-pole tripping, with automatic reclosure, with synchronism check 8
Port E: FO5 optical, 820 nm, 2 ST connectors, length of optical fibre up to 1.5 km,
for FO direct connection or communication networks using multimode fibre
A
Port E: FO6 optical, 820 nm, 2 ST connectors, length of optical fibre up to 3.5 km,
for FO direct connection using multimode fibre
B
Port E: FO17 optical, 1300 nm, LC duplex connector, length of optical fibre up to 24 km,
for FO direct connection using monomode fibre
1)
G
Port E: FO18 optical, 1300 nm, LC duplex connector, length of optical fibre up to 60 km,
for FO direct connection using monomode fibre
1)
H
Port E: FO19 optical, 1550 nm, LC duplex connector, length of optical fibre up to 100 km,
for FO direct connection using monomode fibre
1)
J
Port E: FO30 optical, 820 nm, 2 ST connectors, length of optical fibre up to 1.5 km,
for FO direct connection or communication networks with IEEE C37.94 interface using multimode
fibre
2)
S
