Appendix
A.1 Ordering Information and Accessories
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
651
Short-Circuit Links
Short-circuit Links as Jumper Kit Order No.
3 pcs for current terminals + 6 pcs for voltage terminals C73334-A1-C40-1
Plug-in Connector
Plug-in Connector Order No.
2-pin C73334-A1-C35-1
3-pin C73334-A1-C36-1
Mounting Brackets for 19" Racks
Name Order No.
a pair of mounting rails; one for top, one for bottom C73165-A63-D200-1
Battery
Lithium battery 3 V/1 Ah, type CR 1/2 AA Order No.
VARTA 6127 101 501
Interface Cable
An interface cable and the DIGSI operating software are required for the communication between the SIPRO-
TEC 4 device and a PC or laptop: The PC or laptop must run MS-WINDOWS 95, MS-WINDOWS 98, MS-
WINDOWS NT 4, MS-WINDOWS 2000, MS-WINDOWS ME, MS-WINDOWS XP PRO or MS-WINDOWS
VISTA
Name Order No.
Interface cable between PC and SIPROTEC, Cable with 9-pin male/female con-
nectors
7XV5100-4
