Appendix
A.1 Ordering Information and Accessories
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
650
Exchangeable Interface Modules
Name Order Number
RS232 C53207-A351-D641-1
RS485 C73207-A351-D642-1
FO 820 nm C53207-A351-D643-1
Profibus DP RS485 C53207-A351-D611-1
Profibus DP double ring C53207-A351-D613-1
Profibus FMS RS485 C53207-A351-D603-1
Profibus FMS double ring C53207-A351-D606-1
DNP 3.0 RS485 C53207-A351-D631-1
DNP 3.0 820 nm C53207-A351-D633-1
FO5 with ST connector; 820 nm; multimode optical fibre -
maximum length: 1.5 km (0.94 miles)
1)
C53207-A351-D651-1
FO5 with ST connector; 820 nm; multimode optical fibre -
maximum length: 1.5 km (0.94 miles); for surface mounting housing
1)
C53207-A406-D49-1
FO6 with ST-connector; 820 nm; multimode optical fibre -
maximum length: 3.5 km (2.2 miles) C53207-A351-D652-1
FO6 with ST connector; 820 nm; multimode optical fibre -
maximum length: 3.5 km; for surface mounting housing C53207-A406-D50-1
FO17 with LC duplex connector; 1300 nm; monomode optical fibre -
maximum length: 24 km (15 miles) C53207-A351-D655-1
FO18 with LC duplex connector; 1300 nm; monomode optical fibre -
maximum length: 60 km (37.5 miles) C53207-A351-D656-1
FO19 with LC duplex connector; 1550 nm; monomode optical fibre -
maximum length: 100 km (62.5 miles) C53207-A351-D657-1
FO30 with ST connector; 820 nm; multimode optical fibre -
maximum length: 1.5 km (0.94 miles) (IEEE C37.94 interface)
2)
C53207-A351-D658-1
Ethernet electrical (EN 100) C53207-A351-D675-2
Ethernet optical (EN 100) C53207-A351-D678-1
1)
also used for connection to the optical-electrical communication converter
2)
Module FO30 can only be used in a flush mounting housing
Terminal Block Covering Caps
Terminal Block Covering Cap for Block Type Order No.
18 terminal voltage, 12 terminal current block C73334-A1-C31-1
12 terminal voltage, 8 terminal current block C73334-A1-C32-1
