A.8 Information List
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
707
- Setting Group A is active (P-GrpA
act)
Change Group IntSP on
off
* * LED BO 192 23 1 Yes
- Setting Group B is active (P-GrpB
act)
Change Group IntSP on
off
* * LED BO 192 24 1 Yes
- Setting Group C is active (P-
GrpC act)
Change Group IntSP on
off
* * LED BO 192 25 1 Yes
- Setting Group D is active (P-
GrpD act)
Change Group IntSP on
off
* * LED BO 192 26 1 Yes
- Fault Recording Start (FltRecSta) Osc. Fault Rec. IntSP on
off
*mLEDBO
- Reset Minimum and Maximum
counter (ResMinMax)
Min/Max meter IntSP
_Ev
ON *
- CB1-TEST trip/close - Only L1
(CB1tst L1)
Testing - * *
- CB1-TEST trip/close - Only L2
(CB1tst L2)
Testing - * *
- CB1-TEST trip/close - Only L3
(CB1tst L3)
Testing - * *
- CB1-TEST trip/close Phases
L123 (CB1tst 123)
Testing - * *
- Controlmode REMOTE (ModeR-
EMOTE)
Cntrl Authority IntSP on
off
* LED BO
- Control Authority (Cntrl Auth) Cntrl Authority IntSP on
off
* LED BO 101 85 1 Yes
- Controlmode LOCAL (ModeLO-
CAL)
Cntrl Authority IntSP on
off
* LED BO 101 86 1 Yes
- Breaker (Breaker) Control Device CF_D
12
on
off
* BO 240 160 20
- Breaker (Breaker) Control Device DP on
off
* BI CB 240 160 1 Yes
- Disconnect Switch (Disc.Swit.) Control Device CF_D
2
on
off
* BO 240 161 20
- Disconnect Switch (Disc.Swit.) Control Device DP on
off
* BI CB 240 161 1 Yes
- Earth Switch (EarthSwit) Control Device CF_D
2
on
off
* BO 240 164 20
- Earth Switch (EarthSwit) Control Device DP on
off
* BI CB 240 164 1 Yes
- Interlocking: Breaker Open (Brk
Open)
Control Device IntSP * * *
- Interlocking: Breaker Close (Brk
Close)
Control Device IntSP * * *
- Interlocking: Disconnect switch
Open (Disc.Open)
Control Device IntSP * * *
- Interlocking: Disconnect switch
Close (Disc.Close)
Control Device IntSP * * *
- Interlocking: Earth switch Open
(E Sw Open)
Control Device IntSP * * *
- Interlocking: Earth switch Close
(E Sw Cl.)
Control Device IntSP * * *
- Q2 Open/Close (Q2 Op/Cl) Control Device CF_D
2
on
off
* BO 240 162 20
- Q2 Open/Close (Q2 Op/Cl) Control Device DP on
off
* BI CB 240 162 1 Yes
- Q9 Open/Close (Q9 Op/Cl) Control Device CF_D
2
on
off
* BO 240 163 20
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
