Siemens SIPROTEC User Manual

Appendix
A.8 Information List
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
708
- Q9 Open/Close (Q9 Op/Cl) Control Device DP on
off
* BI CB 240 163 1 Yes
- Fan ON/OFF (Fan ON/OFF) Control Device CF_D
2
on
off
* BO 240 175 20
- Fan ON/OFF (Fan ON/OFF) Control Device DP on
off
* BI CB 240 175 1 Yes
- >Cabinet door open (>Door
open)
Process Data SP on
off
**LEDBIBOCB10111Yes
- >CB waiting for Spring charged
(>CB wait)
Process Data SP on
off
**LEDBIBOCB10121Yes
- >Error Motor Voltage (>Err Mot
U)
Process Data SP on
off
* * LED BI BO CB 240 181 1 Yes
- >Error Control Voltage (>ErrCntr-
lU)
Process Data SP on
off
* * LED BI BO CB 240 182 1 Yes
- >SF6-Loss (>SF6-Loss) Process Data SP on
off
* * LED BI BO CB 240 183 1 Yes
- >Error Meter (>Err Meter) Process Data SP on
off
* * LED BI BO CB 240 184 1 Yes
- >Transformer Temperature (>Tx
Tem p. )
Process Data SP on
off
* * LED BI BO CB 240 185 1 Yes
- >Transformer Danger (>Tx
Danger)
Process Data SP on
off
* * LED BI BO CB 240 186 1 Yes
- Reset meter (Meter res) Energy IntSP
_Ev
ON *
- Error Systeminterface (SysIn-
tErr.)
Protocol IntSP on
off
LED BO
- Threshold Value 1 (ThreshVal1) Thresh.-Switch IntSP on
off
**LEDBIFC
TN
BO CB
3 >Synchronize Internal Real Time
Clock (>Time Synch)
Device SP * * * LED BI BO
4 >Trigger Waveform Capture
(>Trig.Wave.Cap.)
Osc. Fault Rec. SP on * m LED BI BO
5 >Reset LED (>Reset LED) Device SP * * * LED BI BO
7 >Setting Group Select Bit 0 (>Set
Group Bit0)
Change Group SP * * * LED BI BO
8 >Setting Group Select Bit 1 (>Set
Group Bit1)
Change Group SP * * * LED BI BO
009.0100 Failure EN100 Modul (Failure
Modul)
EN100-Modul 1 IntSP on
off
* LED BO
009.0101 Failure EN100 Link Channel 1
(Ch1) (Fail Ch1)
EN100-Modul 1 IntSP on
off
* LED BO
009.0102 Failure EN100 Link Channel 2
(Ch2) (Fail Ch2)
EN100-Modul 1 IntSP on
off
* LED BO
11 >User defined annunciation 1
(>Annunc. 1)
Device SP * * * * LED BI BO 192 27 1 Yes
12 >User defined annunciation 2
(>Annunc. 2)
Device SP * * * * LED BI BO 192 28 1 Yes
13 >User defined annunciation 3
(>Annunc. 3)
Device SP * * * * LED BI BO 192 29 1 Yes
14 >User defined annunciation 4
(>Annunc. 4)
Device SP * * * * LED BI BO 192 30 1 Yes
15 >Test mode (>Test mode) Device SP on
off
* * LED BI BO 135 53 1 Yes
16 >Stop data transmission
(>DataStop)
Device SP * * * LED BI BO 135 54 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
