A.8 Information List
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
714
1027 Accumulation of interrupted
current L1 (Σ IL1 =)
Statistics VI
1028 Accumulation of interrupted
current L2 (Σ IL2 =)
Statistics VI
1029 Accumulation of interrupted
current L3 (Σ IL3 =)
Statistics VI
1030 Max. fault current Phase L1 (Max
IL1 =)
Statistics VI
1031 Max. fault current Phase L2 (Max
IL2 =)
Statistics VI
1032 Max. fault current Phase L3 (Max
IL3 =)
Statistics VI
1111 Fault locator active (FL active) Fault Locator OUT on
off
**LEDBO
1114 Flt Locator: primary RESIS-
TANCE (Rpri =)
Fault Locator VI on off 151 14 4 No
1115 Flt Locator: primary REAC-
TANCE (Xpri =)
Fault Locator VI on off 151 15 4 No
1117 Flt Locator: secondary RESIS-
TANCE (Rsec =)
Fault Locator VI on off 151 17 4 No
1118 Flt Locator: secondary REAC-
TANCE (Xsec =)
Fault Locator VI on off 151 18 4 No
1119 Flt Locator: Distance to fault (dist
=)
Fault Locator VI on off 151 19 4 No
1120 Flt Locator: Distance [%] to fault
(d[%] =)
Fault Locator VI on off 151 20 4 No
1122 Flt Locator: Distance to fault (dist
=)
Fault Locator VI on off 151 22 4 No
1123 Fault Locator Loop L1E (FL Loop
L1E)
Fault Locator OUT_
Ev
on
1124 Fault Locator Loop L2E (FL Loop
L2E)
Fault Locator OUT_
Ev
on
1125 Fault Locator Loop L3E (FL Loop
L3E)
Fault Locator OUT_
Ev
on
1126 Fault Locator Loop L1L2 (FL
Loop L1L2)
Fault Locator OUT_
Ev
on
1127 Fault Locator Loop L2L3 (FL
Loop L2L3)
Fault Locator OUT_
Ev
on
1128 Fault Locator Loop L3L1 (FL
Loop L3L1)
Fault Locator OUT_
Ev
on
1131 Flt Locator: primary FAULT RE-
SISTANCE (RFpri=)
Fault Locator VI on off 151 31 4 No
1132 Fault location invalid (Flt.Loc.in-
valid)
Fault Locator OUT * on * LED BO
1133 Fault locator setting error K0,an-
gle(K0) (Flt.Loc.ErrorK0)
Fault Locator OUT * ON * LED BO
1134 Two ended fault location (two
ended FO)
Fault Locator OUT_
Ev
on
1143 BCD Fault location [1%] (BCD
d[1%])
Fault Locator OUT * * LED BO
1144 BCD Fault location [2%] (BCD
d[2%])
Fault Locator OUT * * LED BO
1145 BCD Fault location [4%] (BCD
d[4%])
Fault Locator OUT * * LED BO
1146 BCD Fault location [8%] (BCD
d[8%])
Fault Locator OUT * * LED BO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
