Appendix
A.8 Information List
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
715
1147 BCD Fault location [10%] (BCD
d[10%])
Fault Locator OUT * * LED BO
1148 BCD Fault location [20%] (BCD
d[20%])
Fault Locator OUT * * LED BO
1149 BCD Fault location [40%] (BCD
d[40%])
Fault Locator OUT * * LED BO
1150 BCD Fault location [80%] (BCD
d[80%])
Fault Locator OUT * * LED BO
1151 BCD Fault location [100%] (BCD
d[100%])
Fault Locator OUT * * LED BO
1152 BCD Fault location valid (BCD
dist. VALID)
Fault Locator OUT * * LED BO
1219 Active 3I0sen (sensitive Ie) =
(3I0senA=)
Sens. Earth Flt VI * * ON
OFF
1220 Reactive 3I0sen (sensitive Ie) =
(3I0senR=)
Sens. Earth Flt VI * * ON
OFF
1251 >Switch on sensitive E/F detec-
tion (>SensEF on)
Sens. Earth Flt SP * * * LED BI BO
1252 >Switch off sensitive E/F detec-
tion (>SensEF off)
Sens. Earth Flt SP * * * LED BI BO
1253 >Block sensitive E/F detection
(>SensEF block)
Sens. Earth Flt SP * * * LED BI BO
1260 Sensitve E/F detection ON/OFF
via BI (SensEF on/offBI)
Sens. Earth Flt IntSP on
off
**LEDBO
1261 Sensitve E/F detection is
switched OFF (SensEF OFF)
Sens. Earth Flt OUT on
off
**LEDBO
1262 Sensitve E/F detection is
BLOCKED (SensEF BLOCK)
Sens. Earth Flt OUT on
off
on off * LED BO
1263 Sensitve E/F detection is ACTIVE
(SensEF ACTIVE)
Sens. Earth Flt OUT on
off
**LEDBO
1271 Sensitve E/F detection picked up
(SensEF Pickup)
Sens. Earth Flt OUT * on off * * LED BO
1272 Sensitve E/F detection Phase L1
(SensEF Phase L1)
Sens. Earth Flt OUT * * ON * LED BO
1273 Sensitve E/F detection Phase L2
(SensEF Phase L2)
Sens. Earth Flt OUT * * ON * LED BO
1274 Sensitve E/F detection Phase L3
(SensEF Phase L3)
Sens. Earth Flt OUT * * ON * LED BO
1276 Sensitve E/F detection Forward
(SensEF Forward)
Sens. Earth Flt OUT * * ON * LED BO
1277 Sensitve E/F detection Reverse
(SensEF Reverse)
Sens. Earth Flt OUT * * ON * LED BO
1278 Sensitve E/F detection Undef. Di-
rection (SensEF undefDir)
Sens. Earth Flt OUT * * ON * LED BO
1281 Sensitve E/F detection TRIP
command (SensEF TRIP)
Sens. Earth Flt OUT * on ON * LED BO
1291 Sensitve E/F detection 3U0>
pickup (SensEF 3U0>)
Sens. Earth Flt OUT * * * LED BO
1305 >Earth Fault O/C Block 3I0>>>
(>EF BLK 3I0>>>)
Earth Fault O/C SP on
off
* * LED BI BO 166 5 1 Yes
1307 >Earth Fault O/C Block 3I0>>
(>EF BLOCK 3I0>>)
Earth Fault O/C SP on
off
* * LED BI BO 166 7 1 Yes
1308 >Earth Fault O/C Block 3I0> (>EF
BLOCK 3I0>)
Earth Fault O/C SP on
off
* * LED BI BO 166 8 1 Yes
1309 >Earth Fault O/C Block 3I0p (>EF
BLOCK 3I0p)
Earth Fault O/C SP on
off
* * LED BI BO 166 9 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
