Siemens SIPROTEC User Manual

Appendix
A.8 Information List
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
716
1310 >Earth Fault O/C Instantaneous
trip (>EF InstTRIP)
Earth Fault O/C SP on
off
on off * LED BI BO 166 10 1 Yes
1311 >E/F Teleprotection ON (>EF
Teleprot.ON)
Teleprot. E/F SP * * * LED BI BO
1312 >E/F Teleprotection OFF (>EF
TeleprotOFF)
Teleprot. E/F SP * * * LED BI BO
1313 >E/F Teleprotection BLOCK (>EF
TeleprotBLK)
Teleprot. E/F SP on
off
* * LED BI BO 166 13 1 Yes
1318 >E/F Carrier RECEPTION,
Channel 1 (>EF Rec.Ch1)
Teleprot. E/F SP on
off
on * LED BI BO 166 18 1 Yes
1319 >E/F Carrier RECEPTION,
Channel 2 (>EF Rec.Ch2)
Teleprot. E/F SP on
off
on * LED BI BO 166 19 1 Yes
1320 >E/F Unblocking: UNBLOCK,
Channel 1 (>EF UB ub 1)
Teleprot. E/F SP on
off
on * LED BI BO 166 20 1 Yes
1321 >E/F Unblocking: BLOCK,
Channel 1 (>EF UB bl 1)
Teleprot. E/F SP on
off
on * LED BI BO 166 21 1 Yes
1322 >E/F Unblocking: UNBLOCK,
Channel 2 (>EF UB ub 2)
Teleprot. E/F SP on
off
on * LED BI BO 166 22 1 Yes
1323 >E/F Unblocking: BLOCK,
Channel 2 (>EF UB bl 2)
Teleprot. E/F SP on
off
on * LED BI BO 166 23 1 Yes
1324 >E/F BLOCK Echo Signal (>EF
BlkEcho)
Teleprot. E/F SP on
off
on * LED BI BO 166 24 1 Yes
1325 >E/F Carrier RECEPTION,
Channel 1, Ph.L1 (>EF Rec.Ch1
L1)
Teleprot. E/F SP on
off
on * LED BI BO 166 25 1 Yes
1326 >E/F Carrier RECEPTION,
Channel 1, Ph.L2 (>EF Rec.Ch1
L2)
Teleprot. E/F SP on
off
on * LED BI BO 166 26 1 Yes
1327 >E/F Carrier RECEPTION,
Channel 1, Ph.L3 (>EF Rec.Ch1
L3)
Teleprot. E/F SP on
off
on * LED BI BO 166 27 1 Yes
1328 >E/F Unblocking: UNBLOCK
Chan. 1, Ph.L1 (>EF UB ub 1-L1)
Teleprot. E/F SP on
off
on * LED BI BO 166 28 1 Yes
1329 >E/F Unblocking: UNBLOCK
Chan. 1, Ph.L2 (>EF UB ub 1-L2)
Teleprot. E/F SP on
off
on * LED BI BO 166 29 1 Yes
1330 >E/F Unblocking: UNBLOCK
Chan. 1, Ph.L3 (>EF UB ub 1-L3)
Teleprot. E/F SP on
off
on * LED BI BO 166 30 1 Yes
1331 Earth fault protection is switched
OFF (E/F Prot. OFF)
Earth Fault O/C OUT on
off
* * LED BO 166 31 1 Yes
1332 Earth fault protection is
BLOCKED (E/F BLOCK)
Earth Fault O/C OUT on
off
on off * LED BO 166 32 1 Yes
1333 Earth fault protection is ACTIVE
(E/F ACTIVE)
Earth Fault O/C OUT * * * LED BO 166 33 1 Yes
1335 Earth fault protection Trip is
blocked (EF TRIP BLOCK)
Earth Fault O/C OUT on
off
on off * LED BO
1336 E/F phase selector L1 selected
(E/F L1 selec.)
Earth Fault O/C OUT * on off * LED BO
1337 E/F phase selector L2 selected
(E/F L2 selec.)
Earth Fault O/C OUT * on off * LED BO
1338 E/F phase selector L3 selected
(E/F L3 selec.)
Earth Fault O/C OUT * on off * LED BO
1345 Earth fault protection PICKED UP
(EF Pickup)
Earth Fault O/C OUT * off * LED BO 166 45 2 Yes
1354 E/F 3I0>>> PICKED UP (EF
3I0>>>Pickup)
Earth Fault O/C OUT * on * LED BO
1355 E/F 3I0>> PICKED UP (EF 3I0>>
Pickup)
Earth Fault O/C OUT * on * LED BO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
