Appendix
A.10 Measured Values
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
749
875 U1 (positive sequence) Voltage Maximum
(U1 Max =)
Min/Max meter - - - - - CFC CD DD
880 Apparent Power Minimum (SMin=) Min/Max meter - - - - - CFC CD DD
881 Apparent Power Maximum (SMax=) Min/Max meter - - - - - CFC CD DD
882 Frequency Minimum (fMin=) Min/Max meter - - - - - CFC CD DD
883 Frequency Maximum (fMax=) Min/Max meter - - - - - CFC CD DD
888 Pulsed Energy Wp (active) (Wp(puls)) Energy 133 55 No 205 - CFC CD DD
889 Pulsed Energy Wq (reactive) (Wq(puls)) Energy 133 56 No 205 - CFC CD DD
924 Wp Forward (Wp+=) Energy 133 51 No 205 - CFC CD DD
925 Wq Forward (Wq+=) Energy 133 52 No 205 - CFC CD DD
928 Wp Reverse (Wp-=) Energy 133 53 No 205 - CFC CD DD
929 Wq Reverse (Wq-=) Energy 133 54 No 205 - CFC CD DD
963 I L1 demand (IL1dmd=) Demand meter - - - - - CFC CD DD
964 I L2 demand (IL2dmd=) Demand meter - - - - - CFC CD DD
965 I L3 demand (IL3dmd=) Demand meter - - - - - CFC CD DD
966 R L1E (R L1E=) Measurement - - - - - CFC CD DD
967 R L2E (R L2E=) Measurement - - - - - CFC CD DD
970 R L3E (R L3E=) Measurement - - - - - CFC CD DD
971 R L12 (R L12=) Measurement - - - - - CFC CD DD
972 R L23 (R L23=) Measurement - - - - - CFC CD DD
973 R L31 (R L31=) Measurement - - - - - CFC CD DD
974 X L1E (X L1E=) Measurement - - - - - CFC CD DD
975 X L2E (X L2E=) Measurement - - - - - CFC CD DD
976 X L3E (X L3E=) Measurement - - - - - CFC CD DD
977 X L12 (X L12=) Measurement - - - - - CFC CD DD
978 X L23 (X L23=) Measurement - - - - - CFC CD DD
979 X L31 (X L31=) Measurement - - - - - CFC CD DD
1040 Active Power Minimum Forward (Pmin
Forw=)
Min/Max meter - - - - - CFC CD DD
1041 Active Power Maximum Forward (Pmax
Forw=)
Min/Max meter - - - - - CFC CD DD
1042 Active Power Minimum Reverse (Pmin Rev
=)
Min/Max meter - - - - - CFC CD DD
1043 Active Power Maximum Reverse (Pmax Rev
=)
Min/Max meter - - - - - CFC CD DD
1044 Reactive Power Minimum Forward (Qmin
Forw=)
Min/Max meter - - - - - CFC CD DD
1045 Reactive Power Maximum Forward (Qmax
Forw=)
Min/Max meter - - - - - CFC CD DD
1046 Reactive Power Minimum Reverse (Qmin
Rev =)
Min/Max meter - - - - - CFC CD DD
1047 Reactive Power Maximum Reverse (Qmax
Rev =)
Min/Max meter - - - - - CFC CD DD
1048 Power Factor Minimum Forward (PFmin-
Forw=)
Min/Max meter - - - - - CFC CD DD
1049 Power Factor Maximum Forward (PFmax-
Forw=)
Min/Max meter - - - - - CFC CD DD
1050 Power Factor Minimum Reverse (PFmin
Rev=)
Min/Max meter - - - - - CFC CD DD
1051 Power Factor Maximum Reverse (PFmax
Rev=)
Min/Max meter - - - - - CFC CD DD
1052 Active Power Demand Forward (Pdmd
Forw=)
Demand meter - - - - - CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
